23. Quarterly Financial Data
The following tables contain selected unaudited consolidated statements of operations data for each quarter of 2021 and 2020 (in thousands, except per share data):
Quarters Ended
Fiscal 2021April 3,
2021
July 3,
2021
October 2,
2021
January 1,
2022
Total revenue$299,043 $305,118 $307,414 $327,578
Gross profit196,875 192,912 203,664 214,896
Operating income65,664 65,136 67,611 77,411
Net income53,375 50,235 57,771 68,258
Net income per share
Basic(1)
$0.97 $0.91 $1.05 $1.23
Diluted(1)
$0.92 $0.88 $1.00 $1.18
Quarters Ended
Fiscal 2020March 28,
2020
June 27,
2020
September 26,
2020
January 2,
2021
Total revenue$269,625 $300,953 $278,112 $295,054
Gross profit185,629 191,584 178,926 186,926
Operating income69,010 62,220 59,698 64,895
Net income 64,456 55,772 49,405 70,649
Net income per share
Basic(1)
$1.20 $1.02 $0.90 $1.28
Diluted(1)
$1.12 $0.96 $0.85 $1.21
______________
(1) The sum of the basic and diluted earnings per share numbers for each quarter may not equal the basic and diluted earnings per share number for the entire year due to quarterly rounding.
The following tables contain selected unaudited consolidated statements of operations data for each quarter of 2021 and 2020 (in thousands, except per share data):
Quarters Ended
Fiscal 2021April 3,
2021
July 3,
2021
October 2,
2021
January 1,
2022
Total revenue$299,043 $305,118 $307,414 $327,578
Gross profit196,875 192,912 203,664 214,896
Operating income65,664 65,136 67,611 77,411
Net income53,375 50,235 57,771 68,258
Net income per share
Basic(1)
$0.97 $0.91 $1.05 $1.23
Diluted(1)
$0.92 $0.88 $1.00 $1.18
Quarters Ended
Fiscal 2020March 28,
2020
June 27,
2020
September 26,
2020
January 2,
2021
Total revenue$269,625 $300,953 $278,112 $295,054
Gross profit185,629 191,584 178,926 186,926
Operating income69,010 62,220 59,698 64,895
Net income 64,456 55,772 49,405 70,649
Net income per share
Basic(1)
$1.20 $1.02 $0.90 $1.28
Diluted(1)
$1.12 $0.96 $0.85 $1.21
______________
(1) The sum of the basic and diluted earnings per share numbers for each quarter may not equal the basic and diluted earnings per share number for the entire year due to quarterly rounding.
299,043305,118307,414327,578196,875192,912203,664214,89665,66465,13667,61177,41153,37550,23557,77168,2580.970.911.051.230.920.881.001.18269,625300,953278,112185,629191,584178,92669,01062,22059,69864,45655,77249,4051.201.020.901.120.960.85
00009375562021-01-032022-01-0100009375562021-07-03iso4217:USD00009375562022-01-29xbrli:shares0000937556us-gaap:SubsequentEventMember2022-02-152022-02-150000937556us-gaap:SubsequentEventMember2022-02-1500009375562022-01-0100009375562021-01-02iso4217:USDxbrli:shares00009375562019-12-292021-01-0200009375562018-12-302019-12-280000937556us-gaap:CommonStockMember2018-12-290000937556us-gaap:TreasuryStockMember2018-12-290000937556us-gaap:AdditionalPaidInCapitalMember2018-12-290000937556us-gaap:AccumulatedOtherComprehensiveIncomeMember2018-12-290000937556us-gaap:RetainedEarningsMember2018-12-2900009375562018-12-290000937556us-gaap:CommonStockMember2018-12-302019-12-280000937556us-gaap:AdditionalPaidInCapitalMember2018-12-302019-12-280000937556us-gaap:TreasuryStockMember2018-12-302019-12-280000937556us-gaap:RetainedEarningsMember2018-12-302019-12-280000937556us-gaap:RetainedEarningsMemberus-gaap:AccountingStandardsUpdate201602Member2018-12-302019-12-280000937556us-gaap:AccumulatedOtherComprehensiveIncomeMember2018-12-302019-12-280000937556us-gaap:CommonStockMember2019-12-280000937556us-gaap:TreasuryStockMember2019-12-280000937556us-gaap:AdditionalPaidInCapitalMember2019-12-280000937556us-gaap:AccumulatedOtherComprehensiveIncomeMember2019-12-280000937556us-gaap:RetainedEarningsMember2019-12-2800009375562019-12-280000937556us-gaap:CommonStockMember2019-12-292021-01-020000937556us-gaap:AdditionalPaidInCapitalMember2019-12-292021-01-020000937556us-gaap:TreasuryStockMember2019-12-292021-01-020000937556us-gaap:RetainedEarningsMember2019-12-292021-01-020000937556us-gaap:RetainedEarningsMemberus-gaap:AccountingStandardsUpdate201613Member2019-12-292021-01-020000937556us-gaap:AccumulatedOtherComprehensiveIncomeMember2019-12-292021-01-020000937556us-gaap:CommonStockMember2021-01-020000937556us-gaap:TreasuryStockMember2021-01-020000937556us-gaap:AdditionalPaidInCapitalMember2021-01-020000937556us-gaap:AccumulatedOtherComprehensiveIncomeMember2021-01-020000937556us-gaap:RetainedEarningsMember2021-01-020000937556us-gaap:CommonStockMember2021-01-032022-01-010000937556us-gaap:AdditionalPaidInCapitalMember2021-01-032022-01-010000937556us-gaap:TreasuryStockMember2021-01-032022-01-010000937556us-gaap:RetainedEarningsMember2021-01-032022-01-010000937556us-gaap:AccumulatedOtherComprehensiveIncomeMember2021-01-032022-01-010000937556us-gaap:CommonStockMember2022-01-010000937556us-gaap:TreasuryStockMember2022-01-010000937556us-gaap:AdditionalPaidInCapitalMember2022-01-010000937556us-gaap:AccumulatedOtherComprehensiveIncomeMember2022-01-010000937556us-gaap:RetainedEarningsMember2022-01-010000937556srt:MinimumMemberus-gaap:BuildingAndBuildingImprovementsMember2021-01-032022-01-010000937556us-gaap:BuildingAndBuildingImprovementsMembersrt:MaximumMember2021-01-032022-01-010000937556srt:MinimumMemberus-gaap:ComputerEquipmentMember2021-01-032022-01-010000937556us-gaap:ComputerEquipmentMembersrt:MaximumMember2021-01-032022-01-010000937556masi:DemonstrationUnitsMember2021-01-032022-01-010000937556srt:MinimumMembermasi:FurnitureandOfficeEquipmentMember2021-01-032022-01-010000937556srt:MaximumMembermasi:FurnitureandOfficeEquipmentMember2021-01-032022-01-010000937556srt:MinimumMemberus-gaap:MachineryAndEquipmentMember2021-01-032022-01-010000937556us-gaap:MachineryAndEquipmentMembersrt:MaximumMember2021-01-032022-01-010000937556us-gaap:VehiclesMember2021-01-032022-01-010000937556us-gaap:AirTransportationEquipmentMember2021-01-032022-01-010000937556us-gaap:PatentsMember2021-01-032022-01-010000937556us-gaap:TrademarksMember2021-01-032022-01-01masi:segment0000937556srt:MinimumMember2022-01-010000937556srt:MaximumMember2022-01-010000937556srt:MinimumMember2021-01-032022-01-010000937556srt:MaximumMember2021-01-032022-01-010000937556srt:ChiefExecutiveOfficerMemberus-gaap:RestrictedStockUnitsRSUMember2019-12-292021-01-020000937556srt:ChiefExecutiveOfficerMemberus-gaap:RestrictedStockUnitsRSUMember2021-01-032022-01-010000937556srt:ChiefExecutiveOfficerMemberus-gaap:RestrictedStockUnitsRSUMember2018-12-302019-12-2800009375562018-12-300000937556us-gaap:RetainedEarningsMemberus-gaap:AccountingStandardsUpdate201602Member2018-12-290000937556masi:CercacorLaboratoriesMember2021-01-032022-01-010000937556masi:CercacorLaboratoriesMember2019-12-292021-01-020000937556masi:CercacorLaboratoriesMember2018-12-302019-12-280000937556masi:LeasedPropertyMember2021-01-032022-01-01utr:sqft0000937556masi:SubleasedPropertyDomain2021-01-032022-01-010000937556masi:CercacorLaboratoriesMember2022-01-010000937556masi:CercacorLaboratoriesMember2021-01-020000937556masi:NotforProfitOrganizationMember2021-01-032022-01-010000937556masi:NotforProfitOrganizationMember2019-12-292021-01-020000937556masi:NotforProfitOrganizationMember2018-12-302019-12-280000937556masi:LikeMindedEntertainmentMember2021-01-032022-01-010000937556masi:LikeMindedEntertainmentMember2019-12-292021-01-020000937556masi:LikeMindedEntertainmentMember2021-01-020000937556masi:LikeMindedEntertainmentMember2022-01-010000937556masi:LikeMindedLabsMember2021-10-020000937556masi:VantrixCorpMemberus-gaap:PurchaseCommitmentMember2021-07-082021-07-080000937556masi:VantrixCorpMemberus-gaap:OptionMember2021-07-082021-07-080000937556masi:ReimbursementFeeMembersrt:ChiefExecutiveOfficerMember2021-01-032022-01-010000937556masi:ReimbursementFeeMembersrt:ChiefExecutiveOfficerMember2019-12-292021-01-020000937556masi:ReimbursementFeeMembersrt:ChiefExecutiveOfficerMember2018-12-302019-12-280000937556us-gaap:BuildingAndBuildingImprovementsMember2022-01-010000937556us-gaap:BuildingAndBuildingImprovementsMember2021-01-020000937556us-gaap:MachineryAndEquipmentMember2022-01-010000937556us-gaap:MachineryAndEquipmentMember2021-01-020000937556us-gaap:LandMember2022-01-010000937556us-gaap:LandMember2021-01-020000937556masi:AircraftandVehiclesMember2022-01-010000937556masi:AircraftandVehiclesMember2021-01-020000937556us-gaap:ComputerEquipmentMember2022-01-010000937556us-gaap:ComputerEquipmentMember2021-01-020000937556us-gaap:LeaseholdImprovementsMember2022-01-010000937556us-gaap:LeaseholdImprovementsMember2021-01-020000937556us-gaap:OfficeEquipmentMember2022-01-010000937556us-gaap:OfficeEquipmentMember2021-01-020000937556masi:DemonstrationUnitsMember2022-01-010000937556masi:DemonstrationUnitsMember2021-01-020000937556us-gaap:ConstructionInProgressMember2022-01-010000937556us-gaap:ConstructionInProgressMember2021-01-020000937556us-gaap:SubsequentEventMember2022-02-142022-02-14iso4217:CAD0000937556us-gaap:SubsequentEventMember2022-02-140000937556us-gaap:SubsequentEventMember2022-03-160000937556us-gaap:PatentsMember2022-01-010000937556us-gaap:PatentsMember2021-01-020000937556masi:AcquiredTechnologyMember2022-01-010000937556masi:AcquiredTechnologyMember2021-01-020000937556us-gaap:CustomerRelationshipsMember2022-01-010000937556us-gaap:CustomerRelationshipsMember2021-01-020000937556us-gaap:TrademarksMember2022-01-010000937556us-gaap:TrademarksMember2021-01-020000937556us-gaap:LicenseMember2022-01-010000937556us-gaap:LicenseMember2021-01-020000937556us-gaap:LicensingAgreementsMember2022-01-010000937556us-gaap:LicensingAgreementsMember2021-01-020000937556us-gaap:OtherIntangibleAssetsMember2022-01-010000937556us-gaap:OtherIntangibleAssetsMember2021-01-020000937556masi:PatentsAndTrademarksMember2022-01-010000937556masi:PatentsAndTrademarksMember2021-01-020000937556masi:PatentsAndTrademarksMember2019-12-280000937556masi:PatentsAndTrademarksMember2021-01-032022-01-010000937556masi:PatentsAndTrademarksMember2019-12-292021-01-020000937556us-gaap:CustomerRelationshipsMembermasi:ConnectedCareAcquisitionMember2019-12-292020-03-280000937556masi:AcquiredTechnologyMembermasi:ConnectedCareAcquisitionMember2019-12-292020-03-280000937556us-gaap:TrademarksMembermasi:ConnectedCareAcquisitionMember2019-12-292020-03-280000937556masi:TNIMedicalAGAcquisitionMembermasi:AcquiredTechnologyMember2020-03-292020-06-270000937556masi:TNIMedicalAGAcquisitionMemberus-gaap:TrademarksMember2020-03-292020-06-270000937556us-gaap:CustomerRelationshipsMembermasi:TNIMedicalAGAcquisitionMember2020-03-292020-06-270000937556us-gaap:OtherIntangibleAssetsMembermasi:TNIMedicalAGAcquisitionMember2020-03-292020-06-270000937556masi:LiDCOAcquisitionMembermasi:AcquiredTechnologyMember2020-09-272021-01-020000937556us-gaap:TrademarksMembermasi:LiDCOAcquisitionMember2020-09-272021-01-020000937556us-gaap:CustomerRelationshipsMembermasi:LiDCOAcquisitionMember2020-09-272021-01-020000937556us-gaap:OtherIntangibleAssetsMembermasi:LiDCOAcquisitionMember2020-09-272021-01-020000937556masi:ConnectedCareAcquisitionMember2019-12-292020-03-280000937556masi:TNIMedicalAGAcquisitionMember2020-03-292020-06-270000937556masi:LiDCOAcquisitionMember2020-09-272021-01-02xbrli:pure0000937556us-gaap:OtherLiabilitiesMember2022-01-010000937556us-gaap:BuildingMember2021-01-032022-01-010000937556us-gaap:EquipmentMember2021-01-032022-01-010000937556us-gaap:OtherNoncurrentAssetsMember2022-01-010000937556us-gaap:OtherNoncurrentAssetsMember2021-01-0200009375562027-01-012022-01-0100009375562023-01-012022-01-0100009375562021-01-022022-01-0100009375562022-01-022022-01-0100009375562024-01-022022-01-0100009375562026-01-022022-01-010000937556us-gaap:RevolvingCreditFacilityMember2018-12-170000937556us-gaap:RevolvingCreditFacilityMember2018-12-170000937556us-gaap:ForeignLineOfCreditMember2018-12-170000937556srt:MinimumMemberus-gaap:RevolvingCreditFacilityMemberus-gaap:BaseRateMember2018-12-172018-12-170000937556us-gaap:RevolvingCreditFacilityMembersrt:MaximumMemberus-gaap:BaseRateMember2018-12-172018-12-170000937556masi:EurocurrencyMembersrt:MinimumMemberus-gaap:RevolvingCreditFacilityMember2018-12-172018-12-170000937556masi:EurocurrencyMemberus-gaap:RevolvingCreditFacilityMembersrt:MaximumMember2018-12-172018-12-170000937556us-gaap:RevolvingCreditFacilityMemberus-gaap:FederalFundsEffectiveSwapRateMember2018-12-172018-12-170000937556us-gaap:RevolvingCreditFacilityMemberus-gaap:LondonInterbankOfferedRateLIBORMember2018-12-172018-12-170000937556srt:MinimumMemberus-gaap:RevolvingCreditFacilityMember2018-12-172018-12-170000937556us-gaap:RevolvingCreditFacilityMembersrt:MaximumMember2018-12-172018-12-170000937556us-gaap:RevolvingCreditFacilityMember2021-01-020000937556us-gaap:RevolvingCreditFacilityMember2022-01-010000937556us-gaap:RevolvingCreditFacilityMember2021-01-032022-01-010000937556masi:A2018RepurchaseProgramMemberus-gaap:CommonStockMember2018-07-010000937556masi:A2018RepurchaseProgramMemberus-gaap:CommonStockMember2018-09-112021-09-1100009375562018-09-112021-09-110000937556masi:A2021RepurchaseProgramMemberus-gaap:CommonStockMember2021-10-290000937556masi:A2021RepurchaseProgramMembersrt:ScenarioForecastMemberus-gaap:CommonStockMember2021-10-292024-10-290000937556masi:A2021RepurchaseProgramMemberus-gaap:CommonStockMember2022-01-010000937556masi:A2007StockIncentivePlanDomainsrt:MaximumMember2022-01-010000937556srt:MinimumMembermasi:A2017EquityIncentivePlanDomain2022-01-010000937556masi:A2017EquityIncentivePlanDomain2021-01-032022-01-010000937556masi:A2017EquityIncentivePlanDomainsrt:MaximumMember2022-01-010000937556us-gaap:EmployeeStockOptionMember2021-01-032022-01-010000937556us-gaap:EmployeeStockOptionMember2019-12-292021-01-020000937556us-gaap:EmployeeStockOptionMember2018-12-302019-12-280000937556us-gaap:EmployeeStockOptionMember2022-01-010000937556masi:PriceRangeOneMember2021-01-032022-01-010000937556masi:PriceRangeOneMember2022-01-010000937556masi:PriceRangeOneMember2021-01-020000937556masi:PriceRangeOneMember2019-12-292021-01-020000937556masi:PriceRangeTwoMember2021-01-032022-01-010000937556masi:PriceRangeTwoMember2022-01-010000937556masi:PriceRangeTwoMember2021-01-020000937556masi:PriceRangeTwoMember2019-12-292021-01-020000937556masi:PriceRangeThreeMember2021-01-032022-01-010000937556masi:PriceRangeThreeMember2022-01-010000937556masi:PriceRangeThreeMember2021-01-020000937556masi:PriceRangeThreeMember2019-12-292021-01-020000937556masi:PriceRangeFourMember2021-01-032022-01-010000937556masi:PriceRangeFourMember2022-01-010000937556masi:PriceRangeFourMember2021-01-020000937556masi:PriceRangeFourMember2019-12-292021-01-020000937556masi:PriceRangeFiveMember2021-01-032022-01-010000937556masi:PriceRangeFiveMember2022-01-010000937556masi:PriceRangeFiveMember2021-01-020000937556masi:PriceRangeFiveMember2019-12-292021-01-020000937556masi:PriceRangeSixMember2021-01-032022-01-010000937556masi:PriceRangeSixMember2022-01-010000937556masi:PriceRangeSixMember2021-01-020000937556masi:PriceRangeSixMember2019-12-292021-01-020000937556masi:PriceRangeSevenMember2021-01-032022-01-010000937556masi:PriceRangeSevenMember2022-01-010000937556masi:PriceRangeSevenMember2021-01-020000937556masi:PriceRangeSevenMember2019-12-292021-01-020000937556us-gaap:RestrictedStockUnitsRSUMember2021-01-020000937556us-gaap:RestrictedStockUnitsRSUMember2019-12-280000937556us-gaap:RestrictedStockUnitsRSUMember2018-12-290000937556us-gaap:RestrictedStockUnitsRSUMember2021-01-032022-01-010000937556us-gaap:RestrictedStockUnitsRSUMember2019-12-292021-01-020000937556us-gaap:RestrictedStockUnitsRSUMember2018-12-302019-12-280000937556us-gaap:RestrictedStockUnitsRSUMember2022-01-010000937556us-gaap:PerformanceSharesMember2021-01-020000937556us-gaap:PerformanceSharesMember2019-12-280000937556us-gaap:PerformanceSharesMember2018-12-290000937556us-gaap:PerformanceSharesMember2021-01-032022-01-010000937556us-gaap:PerformanceSharesMember2019-12-292021-01-020000937556us-gaap:PerformanceSharesMember2018-12-302019-12-280000937556us-gaap:PerformanceSharesMember2022-01-010000937556us-gaap:PerformanceSharesMembersrt:MinimumMember2018-12-302019-12-280000937556us-gaap:PerformanceSharesMembermasi:A2018GrantMembersrt:MinimumMember2019-12-280000937556us-gaap:PerformanceSharesMembermasi:A2018GrantMembersrt:MaximumMember2019-12-280000937556us-gaap:PerformanceSharesMembersrt:MaximumMember2018-12-302019-12-280000937556us-gaap:PerformanceSharesMembersrt:MinimumMember2019-12-292021-01-020000937556us-gaap:PerformanceSharesMembersrt:MinimumMembermasi:A2019GrantMember2021-01-020000937556us-gaap:PerformanceSharesMembersrt:MaximumMembermasi:A2019GrantMember2021-01-020000937556us-gaap:PerformanceSharesMembersrt:MaximumMember2019-12-292021-01-020000937556us-gaap:PerformanceSharesMembersrt:MinimumMember2021-01-032022-01-010000937556us-gaap:PerformanceSharesMembersrt:MinimumMembermasi:A2020GrantMember2022-01-010000937556us-gaap:PerformanceSharesMembermasi:A2020GrantMembersrt:MaximumMember2022-01-010000937556us-gaap:PerformanceSharesMembersrt:MaximumMember2021-01-032022-01-010000937556srt:MinimumMember2019-12-292021-01-020000937556srt:MaximumMember2019-12-292021-01-020000937556srt:MinimumMember2018-12-302019-12-280000937556srt:MaximumMember2018-12-302019-12-280000937556us-gaap:CostOfSalesMember2021-01-032022-01-010000937556us-gaap:CostOfSalesMember2019-12-292021-01-020000937556us-gaap:CostOfSalesMember2018-12-302019-12-280000937556masi:SellingGeneralAndAdministrativeMember2021-01-032022-01-010000937556masi:SellingGeneralAndAdministrativeMember2019-12-292021-01-020000937556masi:SellingGeneralAndAdministrativeMember2018-12-302019-12-280000937556us-gaap:ResearchAndDevelopmentExpenseMember2021-01-032022-01-010000937556us-gaap:ResearchAndDevelopmentExpenseMember2019-12-292021-01-020000937556us-gaap:ResearchAndDevelopmentExpenseMember2018-12-302019-12-280000937556us-gaap:DomesticCountryMember2022-01-010000937556us-gaap:StateAndLocalJurisdictionMember2022-01-010000937556us-gaap:ForeignCountryMember2022-01-010000937556srt:ChiefExecutiveOfficerMemberus-gaap:CashDistributionMember2017-07-272017-07-270000937556srt:ChiefExecutiveOfficerMemberus-gaap:RestrictedStockUnitsRSUMember2017-07-272017-07-270000937556srt:ChiefExecutiveOfficerMember2022-01-012022-01-010000937556srt:ChiefExecutiveOfficerMemberus-gaap:SubsequentEventMember2022-01-142022-01-14masi:Agreement0000937556masi:UnsecuredBankGuaranteesMember2022-01-010000937556us-gaap:SalesRevenueProductLineMember2021-01-032022-01-010000937556us-gaap:SalesRevenueProductLineMember2019-12-292021-01-020000937556us-gaap:SalesRevenueProductLineMember2018-12-302019-12-280000937556us-gaap:SalesMember2021-01-032022-01-01masi:distributor0000937556us-gaap:SalesMember2019-12-292021-01-020000937556us-gaap:SalesMember2018-12-302019-12-280000937556masi:JustintimedistributoroneMemberus-gaap:SalesRevenueNetMember2021-01-032022-01-010000937556masi:JustintimedistributortwoMemberus-gaap:SalesRevenueNetMember2021-01-032022-01-010000937556masi:JustintimedistributortwoMemberus-gaap:SalesRevenueNetMember2019-12-292021-01-020000937556masi:JustintimedistributoroneMemberus-gaap:SalesRevenueNetMember2019-12-292021-01-020000937556masi:JustintimedistributortwoMemberus-gaap:SalesRevenueNetMember2018-12-302019-12-280000937556masi:JustintimedistributoroneMemberus-gaap:SalesRevenueNetMember2018-12-302019-12-280000937556us-gaap:AccountsReceivableMember2019-12-292021-01-020000937556us-gaap:AccountsReceivableMember2021-01-032022-01-010000937556masi:JustintimedistributoroneMemberus-gaap:AccountsReceivableMember2022-01-010000937556masi:JustintimedistributoroneMemberus-gaap:AccountsReceivableMember2021-01-02masi:Customer0000937556us-gaap:AccountsReceivableMember2022-01-010000937556us-gaap:AccountsReceivableMember2021-01-020000937556masi:MasimovsFormerAgencyTenderMember2018-09-302018-12-290000937556masi:MasimovsFormerAgencyTenderMember2019-12-292021-01-0200009375562019-07-082019-07-080000937556masi:Masimovs.PhysiciansHealthsourceInc.Member2014-01-022014-01-030000937556country:US2021-01-032022-01-010000937556country:US2019-12-292021-01-020000937556country:US2018-12-302019-12-280000937556us-gaap:EMEAMember2021-01-032022-01-010000937556us-gaap:EMEAMember2019-12-292021-01-020000937556us-gaap:EMEAMember2018-12-302019-12-280000937556srt:AsiaPacificMember2021-01-032022-01-010000937556srt:AsiaPacificMember2019-12-292021-01-020000937556srt:AsiaPacificMember2018-12-302019-12-280000937556srt:AmericasMember2021-01-032022-01-010000937556srt:AmericasMember2019-12-292021-01-020000937556srt:AmericasMember2018-12-302019-12-280000937556srt:ReportableGeographicalComponentsMembercountry:US2022-01-010000937556srt:ReportableGeographicalComponentsMembercountry:US2021-01-020000937556srt:ReportableGeographicalComponentsMembercountry:US2019-12-280000937556us-gaap:NonUsMembersrt:ReportableGeographicalComponentsMember2022-01-010000937556us-gaap:NonUsMembersrt:ReportableGeographicalComponentsMember2021-01-020000937556us-gaap:NonUsMembersrt:ReportableGeographicalComponentsMember2019-12-2800009375562021-01-032021-04-0300009375562021-04-042021-07-0300009375562021-07-042021-10-0200009375562021-10-032022-01-0100009375562019-12-292020-03-2800009375562020-03-292020-06-2700009375562020-06-282020-09-260000937556us-gaap:AllowanceForCreditLossMember2021-01-020000937556us-gaap:AllowanceForCreditLossMember2021-01-032022-01-010000937556us-gaap:AllowanceForCreditLossMember2022-01-010000937556us-gaap:ReserveForEarnOutReceivableMember2021-01-020000937556us-gaap:ReserveForEarnOutReceivableMember2021-01-032022-01-010000937556us-gaap:ReserveForEarnOutReceivableMember2022-01-010000937556us-gaap:AllowanceForCreditLossMember2019-12-280000937556us-gaap:AllowanceForCreditLossMember2019-12-292021-01-020000937556us-gaap:ReserveForEarnOutReceivableMember2019-12-280000937556us-gaap:ReserveForEarnOutReceivableMember2019-12-292021-01-020000937556us-gaap:AllowanceForCreditLossMember2018-12-290000937556us-gaap:AllowanceForCreditLossMember2018-12-302019-12-280000937556us-gaap:ReserveForEarnOutReceivableMember2018-12-290000937556us-gaap:ReserveForEarnOutReceivableMember2018-12-302019-12-28
Table of Contents

UNITED STATES
SECURITIES AND EXCHANGE COMMISSION
WASHINGTON, D.C. 20549
________________________________________________
FORM 10-K
________________________________________________________________________
(Mark One)
ANNUAL REPORT PURSUANT TO SECTION 13 OR 15(D) OF THE SECURITIES EXCHANGE ACT OF 1934
For the fiscal year ended January 1, 2022
OR
TRANSITION REPORT PURSUANT TO SECTION 13 OR 15(D) OF THE SECURITIES EXCHANGE ACT OF 1934
For the transition period from _________ to _________
Commission File Number 001-33642
________________________________________________
MASIMO CORPORATION
(Exact name of registrant as specified in its charter)
_________________________________________________________
DE33-0368882
(State or Other Jurisdiction of
Incorporation or Organization)
(I.R.S. Employer
Identification Number)
52 DiscoveryIrvine,CA92618
(Address of principal executive offices)(Zip Code)
(949)297-7000
(Registrant’s telephone number, including area code)
Securities registered pursuant to Section 12(b) of the Act:
Title of each class:Trading symbol:Name of each exchange on which registered:
Common Stock, par value $0.001MASIThe Nasdaq Stock Market, LLC
Securities registered pursuant to Section 12(g) of the Act: None
Indicate by check mark if the registrant is a well-known seasoned issuer, as defined in Rule 405 of the Securities Act.
YesNo
Indicate by check mark if the registrant is not required to file reports pursuant to Section 13 or Section 15(d) of the Act.
YesNo
Indicate by check mark whether the registrant (1) has filed all reports required to be filed by Section 13 or 15(d) of the Securities Exchange Act of 1934 during the preceding 12 months (or for such shorter period that the registrant was required to file such reports), and (2) has been subject to such filing requirements for the past 90 days.
YesNo
Indicate by check mark whether the registrant has submitted electronically every Interactive Data File required to be submitted pursuant to Rule 405 of Regulation S-T (§ 232.405 of this chapter) during the preceding 12 months (or for such shorter period that the registrant was required to submit such files).
YesNo
Indicate by check mark whether the registrant is a large accelerated filer, an accelerated filer, a non-accelerated filer, a smaller reporting company, or an emerging growth company. See the definitions of “large accelerated filer,” “accelerated filer,” “smaller reporting company,” and “emerging growth company” in Rule 12b-2 of the Exchange Act.
Large accelerated filer
Accelerated filer
Non-accelerated filer
Smaller reporting company
Emerging growth company
If an emerging growth company, indicate by check mark if the registrant has elected not to use the extended transition period for complying with any new or revised financial accounting standards provided pursuant to Section 13(a) of the Exchange Act.
Indicate by check mark whether the registrant has filed a report on and attestation to its management’s assessment of the effectiveness of its internal control over financial reporting under Section 404(b) of the Sarbanes-Oxley Act (15 U.S.C. 7262(b)) by the registered public accounting firm that prepared or issued its audit report.
Indicate by check mark whether the registrant is a shell company (as defined in Rule 12b-2 of the Exchange Act.)
Yes
No
The aggregate market value of the voting stock held by non-affiliates of the registrant, based upon the closing sale price of the common stock on July 3, 2021, the last business day of the registrant’s most recently completed second fiscal quarter, as reported on the Nasdaq Global Select Market, was approximately $10.9 billion. Shares of stock held by officers, directors and 5 percent or more stockholders have been excluded in that such persons may be deemed to be affiliates. This determination of affiliate status is not necessarily a conclusive determination for other purposes. At January 29, 2022, the registrant had 55,364,690 shares of common stock outstanding.
DOCUMENTS INCORPORATED BY REFERENCE
Items 10, 11, 12, 13 and 14 of Part III of this Annual Report on Form 10-K incorporate information by reference from the registrant’s proxy statement for the registrant’s 2022 Annual Meeting of Stockholders to be filed with the Securities and Exchange Commission within 120 days after the close of the fiscal year covered by this annual report on Form 10-K.


Table of Contents

MASIMO CORPORATION
FISCAL YEAR 2021 FORM 10-K ANNUAL REPORT
TABLE OF CONTENTS

Page
Item 1
Item 1A
Item 1B
Item 2
Item 3
Item 4
Item 5
Item 6
Item 7
Item 7A
Item 8
Item 9
Item 9A
Item 9B
Item 9C
Item 10
Item 11
Item 12
Item 13
Item 14
Item 15
Item 16



Table of Contents

FORWARD-LOOKING STATEMENTS
This Annual Report on Form 10-K contains “forward-looking statements” that involve risks and uncertainties, as well as assumptions that, if they never materialize or prove incorrect, could cause our results to differ materially and adversely from those expressed or implied by such forward-looking statements. The forward-looking statements are contained principally in Item 1—“Business,” Item 1A—“Risk Factors” and Item 7—“Management’s Discussion and Analysis of Financial Condition and Results of Operations” but appear throughout this Annual Report on Form 10-K. Examples of forward-looking statements include, but are not limited to, any projection or expectation of earnings, revenue or other financial items; the plans, strategies and objectives of management for future operations; factors that may affect our operating results, including accounting and tax estimates; our success in pending litigation; new products or services; the demand for our products; our ability to consummate acquisitions and successfully integrate them into our operations; future capital expenditures; effects of current or future economic conditions or performance; industry trends and other matters that do not relate strictly to historical facts or statements of assumptions underlying any of the foregoing. These statements are often identified by the use of words such as “anticipate,” “believe,” “continue,” “could,” “estimate,” “expect,” “intend,” “may,” “ongoing,” “opportunity,” “plan,” “potential,” “predicts,” “seek,” “should,” “will,” or “would,” and similar expressions and variations or negatives of these words. These forward-looking statements are based on the expectations, estimates, projections, beliefs and assumptions of our management based on information currently available to management, all of which is subject to change. Such forward-looking statements are subject to risks, uncertainties and other factors that are difficult to predict and could cause our actual results and the timing of certain events to differ materially and adversely from future results expressed or implied by such forward-looking statements. Factors that could cause or contribute to such differences include, but are not limited to, those identified below, and those discussed under Item 1A—“Risk Factors” in this Annual Report on Form 10-K. Furthermore, such forward-looking statements speak only as of the date of this Annual Report on Form 10-K. We undertake no obligation to update or revise publicly any forward-looking statements to reflect events or circumstances after the date of such statements for any reason, except as otherwise required by law.
PART I
ITEM 1.     BUSINESS
Overview
We are a global medical technology company that develops, manufactures and markets a variety of noninvasive monitoring technologies and hospital automation solutions. Our mission is to improve patient outcomes and reduce the cost of patient care. Our patient monitoring solutions generally incorporate a monitor or circuit board, proprietary single-patient use or reusable sensors, software and/or cables. We provide our products to hospitals, emergency medical service (EMS) providers, home care providers, long-term care facilities, physician offices, veterinarians and consumers through our direct sales force, distributors and original equipment manufacturers (OEM) partners. We were incorporated in California in May 1989 and reincorporated in Delaware in May 1996.
Our core business is Measure-through Motion and Low Perfusion pulse oximetry, known as Masimo Signal Extraction Technology® (SET®) pulse oximetry. Our product offerings have expanded significantly over the years to also include noninvasive monitoring of blood constituents with an optical signature, optical regional oximetry monitoring, electrical brain function monitoring, acoustic respiration monitoring, exhaled gas monitoring, nasal high flow ventilation, minimally invasive neuromodulation technology for pain and addiction reduction, hospital automation and connectivity solutions and home wellness and monitoring.
These technologies are incorporated into a variety of product platforms designed to meet our customers’ needs. In addition, we provide our technologies to OEMs in a form factor that is easy to integrate into their patient monitors, defibrillators, infant incubators and other devices.
Our technology is supported by a substantial intellectual property portfolio that we have built through internal development and, to a lesser extent, acquisitions and license agreements. We have also exclusively licensed from Cercacor Laboratories, Inc. (Cercacor) the right to certain OEM rainbow® technologies and to incorporate certain rainbow® technology into our products intended to be used by professional caregivers, including, but not limited to, hospital caregivers and alternate care facility caregivers.

1

Table of Contents

Core Business
Conventional Pulse Oximetry
Pulse oximetry enables the noninvasive measurement of the oxygen saturation level of arterial blood (SpO2), which delivers oxygen to the body’s tissues. Pulse oximetry also measures pulse rate (PR), which, when measured by electrocardiogram (ECG), is called heart rate. Pulse oximeters use sensors attached to an extremity, typically the fingertip or certain core body sites. These sensors contain two light-emitting diodes that transmit red and infrared light from one side of the extremity through the tissue to a photodetector on the other side of the extremity. The photodetector in the sensor measures the amount of red and infrared light absorbed by the tissue. A microprocessor then analyzes the changes in light absorption to provide a continuous, real-time measurement of the amount of oxygen in the patient’s arterial blood. Pulse oximeters typically give audio and visual alerts, or alarms, when the patient’s arterial blood oxygen saturation level or pulse rate falls outside of a user-designated range. As a result, clinicians have the opportunity to assess patients who may need immediate treatment to prevent the serious clinical consequences of hypoxemia, or low arterial blood oxygen saturation levels, and hyperoxemia, or high arterial blood oxygen levels.
As one of the most common technologies used in and out of hospitals around the world, pulse oximetry has gained widespread clinical acceptance as a standard patient vital sign measurement because it can give clinicians a warning of possible hypoxemia or hyperoxemia. SpO2 monitoring of oxygen saturation is critical because hypoxemia can lead to a lack of oxygen in the body’s tissues, which can be toxic and result in organ damage or death. Pulse oximeters are used in a variety of critical care settings, including surgery, recovery rooms, intensive care units (ICUs), emergency departments and general care floors, as well as alternative care settings, such as long-term care facilities, physician offices and the home monitoring of patients with chronic conditions.
Clinicians also use pulse oximeters to monitor oxygen saturation in premature babies to ensure that appropriate oxygen saturation levels are maintained. In premature babies, oxygen saturation levels above clinically acceptable limits may lead to a condition known as retinopathy of prematurity (ROP), which, if left untreated, can lead to permanent eye damage or blindness. By ensuring that oxygen saturation levels in babies remain within clinically acceptable limits, clinicians believe they can lower the incidence of ROP.
Conventional pulse oximetry has limitations that can reduce its effectiveness and the quality of patient care. In particular, when using conventional pulse oximetry, oxygen saturation measurements can be distorted by motion artifact, or patient movement, and low perfusion, or low arterial blood flow at the measurement site. Motion artifact can cause conventional pulse oximeters to inaccurately measure the arterial blood oxygen saturation level, due mainly to the effect of movement-induced pulsations of venous blood, which is at a lower oxygen saturation than arterial blood. Low perfusion can also cause conventional pulse oximeters to report inaccurate measurements or, in some cases, no measurement at all. In addition, conventional pulse oximeters cannot distinguish oxygenated hemoglobin from dyshemoglobin, including the most prevalent forms of dyshemoglobins, carboxyhemoglobin and methemoglobin. As a result, conventional pulse oximeters may report falsely high oxygen levels when these dyshemoglobins are present in the blood. Furthermore, conventional pulse oximetry readings can also be impacted by bright light and electrical interference caused by the presence of electrical surgical equipment.
Independent research has shown that over 70% of oxygen saturation alarms outside the operating room are false when conventional pulse oximetry is used. In the operating room, conventional pulse oximeters can fail to give accurate measurements due to weak physiological signals or low perfusion. Manufacturers of pulse oximeters have attempted to address some of these limitations with varying degrees of success. Some competing devices have attempted to minimize the observed effects of motion artifact by repeating/freezing the last measurement before motion artifact was detected until a new, clean signal is detected and a new measurement can be displayed. Other competing devices increase the averaging time during motion, known as long averaging, in an attempt to reduce the observed effect of motion on their measurements. Still other competing devices extend the audible alarm notification delay, which reduces awareness of inaccurate measurements. These competing “motion tolerant” or “alarm management” techniques mask the limitations of conventional pulse oximetry. Several published studies have demonstrated that these also contribute to increased occurrences of undetected true alarms, or events where hypoxemia occurs but is not detected by the pulse oximeter.
Lastly, because conventional pulse oximetry cannot consistently measure SpO2 and pulse rate in the presence of motion artifact or low perfusion, its use is limited in lower acuity settings in the hospital, such as in general care areas, where a hospital’s staff-to-patient ratio is significantly lower and the staff have less tolerance for false alarms. In addition, two-wavelength pulse oximeters cannot distinguish oxygenated hemoglobin from dyshemoglobin, including the most prevalent forms of carboxyhemoglobin and methemoglobin. As a result of these dyshemoglobins, pulse oximeters will report falsely high oxygen levels when they are present in the blood.

2

Table of Contents

Masimo Difference
Masimo SET® Pulse Oximetry
Masimo SET® was designed to overcome the primary limitations of conventional pulse oximetry by maintaining accuracy in the presence of motion artifact, low perfusion and weak signal-to-noise situations. Our Masimo SET® platform, which became available to U.S. hospitals in 1998, is the basis of our pulse oximetry products, and we believe represented the first significant technological advancement in pulse oximetry since its introduction in the early 1980s. Masimo SET® utilizes five signal processing algorithms, four of which are proprietary, in parallel to deliver high sensitivity and specificity in the measurement of arterial blood oxygen saturation levels. Sensitivity is the ability to detect true alarms and specificity is the ability to avoid false alarms. One of our proprietary processing algorithms, Discrete Saturation Transform®, separates the signal from noise in real time through the use of adaptive filtering and an iterative sampling technique that tests each possible saturation value for validity. Masimo SET® signal processing can therefore identify the venous blood and other “noise”, isolate them and extract the arterial signal.
The performance of Masimo SET® pulse oximetry has been evaluated in more than 100 independent studies and thousands of clinical evaluations. We believe that Masimo SET® is trusted by clinicians to safely monitor in excess of approximately 200 million patients each year and has been chosen as the primary pulse oximeter technology used by nine of the top ten hospitals according to the 2021-2022 U.S. News & World Report Best Hospitals Honor Roll. Compared to conventional pulse oximeters, during patient motion and low perfusion, Masimo SET® provides measurements when other pulse oximeters cannot, significantly reduces false alarms (improved specificity), and accurately detects true alarms (improved sensitivity). Clinical studies have shown that the use of Masimo SET® pulse oximetry, in conjunction with modified clinical protocols, has helped clinicians reduce ROP in neonates and improve screening for newborns with critical congenital heart disease (CCHD). Clinical studies have also shown a reduction in rapid response activations and ICU transfers when Masimo SET® is used to continuously monitor patients on general wards. Additionally, researchers have found that the use of Masimo SET® is associated with reduced ventilator weaning time and arterial blood gas measurements in the ICU.
Our pulse oximetry technology is contained on a circuit board which can be placed inside a standalone pulse oximetry monitor, placed inside OEM multiparameter monitors, or included as part of an external “Board-in-Cable” solution that is plugged into a port on an OEM or other device. All of these solutions use our proprietary single-patient-use or reusable sensors and cables. We sell our products to end-users through our direct sales force and through certain distributors, as well as to our OEM partners, for incorporation into their products. In 2013, we also began selling our pulse oximetry products in the consumer market.
To complement our Masimo SET® platform, we have developed a wide range of proprietary single-patient-use (disposable) and multi-patient-use (reusable) sensors, cables and other accessories designed specifically to work with Masimo SET® software and hardware. Our single-patient-use sensors offer several advantages over reusable sensors, including improved performance, cleanliness, increased comfort and greater reliability. In addition, our neonatal adhesive sensors have been designed to exhibit greater durability compared to competitive sensors. Although our technology platforms operate solely with our proprietary sensor lines, our sensors have the capability to work with certain competitive pulse oximetry monitors through the use of adapter cables.
Adhesive sensors are single-patient-use items, but the U.S. Food and Drug Administration (FDA) allows third parties to reprocess pulse oximetry sensors. In response to some hospitals’ requests to implement environmentally friendly or “green” products, we offer sensor reprocessing as well as sensor recycling programs.
Masimo rainbow SET® Platform
Since introducing Masimo SET®, we have continued to innovate by introducing noninvasive measurements that go beyond arterial blood oxygen saturation and pulse rate. Our Masimo rainbow SET® platform leverages our Masimo SET® technology and incorporates licensed rainbow® technology to enable real-time monitoring of additional noninvasive measurements. Our rainbow SET® platform includes our rainbow SET® Pulse CO-Oximetry products, which we believe are the first devices cleared by the FDA to noninvasively and continuously monitor additional hemoglobin species that were previously only measurable using intermittent invasive procedures using multiple wavelengths of light.
In addition to SpO2, PR, perfusion index (Pi), Pleth Variability Index (PVi®) and respiration rate from the pleth (RRp®), rainbow® Pulse CO-Oximetry has the unique ability to measure and distinguish oxygenated hemoglobins from the dyshemoglobins that are incapable of transporting oxygen, carboxyhemoglobin (SpCO®) and methemoglobin (SpMet®). Besides the ability to measure SpCO® and SpMet®, the Masimo rainbow SET® platform also allows for the noninvasive and continuous monitoring of total hemoglobin concentration (SpHb®) as well as the monitoring of arterial oxygen saturation, in the presence of carboxyhemoglobin and methemoglobin, known as fractional arterial oxygen saturation (SpfO2). Additionally, the rainbow SET® platform also allows for the calculation of Oxygen Content (SpOC) and Oxygen Reserve Index (ORi). SpfO2 and ORi have received CE Marking, but are not currently available for sale in the U.S.
3

Table of Contents

We believe that Masimo rainbow® Pulse CO-Oximetry products will become widely adopted for the noninvasive monitoring of these measurements in the future. We also believe that the addition of acoustic respiration rate (RRa®), using our rainbow Acoustic Monitoring® technology, will strengthen the clinical demand for noninvasive and continuous monitoring using our rainbow® platform, especially in the growing general floor market.
Products with our MX circuit board contain our Masimo SET® pulse oximetry technology as well as circuitry to support rainbow® measurements. At the time of purchase, or at any time in the future, our customers and our OEMs’ customers have the option of purchasing additional rainbow® software measurements, which allow such customers to incrementally expand their patient monitoring systems with a cost-effective solution. To date, over forty companies have released rainbow SET® equipped products or announced rainbow® integration plans.
Measurements
SpHb®
Hemoglobin is the oxygen-carrying component of red blood cells (RBCs). Hemoglobin measurement is one of the most frequent invasive laboratory measurements in the world, and is often measured as part of a complete blood count (CBC), which measures multiple other blood components. A low hemoglobin status is a condition called anemia. As a chronic disorder, anemia can be treated by iron supplements, diet changes or drugs that increase the production of RBCs. As an acute disorder resulting from bleeding, anemia requires either stoppage of the bleeding or a blood transfusion in order to sustain organ function and life.
SpHb® is available as a continuous or a spot-check measurement. Continuous SpHb® monitoring provides real-time visibility into hemoglobin levels and the changes, or lack of changes, in hemoglobin levels, which can otherwise only be measured through intermittent, invasive blood testing. SpHb® monitoring is not intended to be used as the sole basis for making diagnosis or treatment decisions, but continuous SpHb® monitoring may help clinicians to trend hemoglobin in real time between invasive blood samples.
SpOC
The oxygen content of blood is a function of both oxygen saturation and hemoglobin levels. SpOC provides a more complete picture of a patient’s oxygenation status by combining noninvasive and continuous measurements of both hemoglobin and oxygen saturation levels into a single calculation.
SpCO®
Carbon monoxide (CO) is a colorless, odorless and tasteless gas that is undetectable by humans and is often unknowingly inhaled from combustion fumes, or during fires by victims and first responders. CO poisoning is the leading cause of accidental poisoning death in the U.S. and is responsible for up to 50,000 emergency department visits and 500 unintentional deaths annually. CO, when bound to hemoglobin cells, prevents those cells from carrying oxygen. Elevated CO levels may cause severe neurological damage, permanent heart damage or death. Screening for elevated CO levels in the emergency department is critical, as symptoms of CO poisoning in patients may be misdiagnosed because such symptoms are similar to the flu.
CO levels in the blood can be measured using a laboratory CO-Oximeter, which requires a patient or a patient’s blood sample to be transported to a hospital with laboratory CO-Oximetry capability. Additional delays occur if a patient needs hyperbaric oxygen therapy, which often requires transfer to yet another medical center with hyperbaric capability. Outside the hospital, laboratory measurements of carboxyhemoglobin are not considered feasible. Historically, this meant that CO levels in the blood could not be assessed in environments in which such assessment would be very useful, such as in the home or as part of the medical evaluation of first responders potentially exposed to CO at the scene of a fire.
While SpCO® is not intended to replace invasive carboxyhemoglobin tests, when used with other clinical variables, SpCO® may help clinicians identify elevated CO levels and help determine additional test and treatment options. Multiple leading emergency first responder associations, including the National Association of Emergency Medical Technicians, the National Association of EMS Educators, the International Association of Fire Fighters and the International Association of Fire Chiefs, have educated their members on the benefits of noninvasive CO measurement when exposure is suspected or when an individual presents symptoms that could indicate elevated CO levels.
4

Table of Contents

SpMet®
Methemoglobin in the blood leads to a dangerous condition known as methemoglobinemia, which occurs as a reaction to some common drugs used in hospitals and outpatient procedures. Methemoglobinemia reduces the amount of oxygen bound to hemoglobin for delivery to tissues and forces normal hemoglobin to bind more tightly to oxygen, releasing less oxygen to the tissues. Methemoglobinemia may go unrecognized or be subject to delayed diagnosis, increasing risk to the patient. Commonly prescribed drugs can introduce methemoglobin into the blood and cause methemoglobinemia. Some of the 30 drugs that are known to cause methemoglobinemia include benzocaine, a local anesthetic routinely used in procedures ranging from endoscopy to surgery; inhaled nitric oxide, routinely used in the Neonatal Intensive Care Unit; nitroglycerin, used to treat cardiac patients; and dapsone, used to treat infections for immune-deficient patients such as Human Immunodeficiency Virus (HIV) patients. Warnings, cautions and alerts regarding the clinical significance and prevalence of methemoglobinemia have been generated by the FDA, the Veterans Administration, the Institute for Safe Medication Practices and the National Academy of Clinical Biochemistry. The American Academy of Pediatrics recommends monitoring methemoglobin levels in infants who receive nitric oxide therapy. While SpMet® is not intended to replace invasive methemoglobin tests, when used with other clinical variables, SpMet® may help clinicians identify elevated methemoglobin levels and help determine additional test and treatment options.
PVi®
PVi® is a measure of the dynamic changes in the Perfusion Index (Pi) that occur during the respiratory cycle. The calculation is accomplished by measuring changes in Pi over a time interval where one or more complete respiratory cycles have occurred. PVi® is displayed as a percentage. The lower the number, the less variability there is in Pi over a respiratory cycle. PVi® may show changes that reflect physiologic factors such as vascular tone, circulating blood volume and intrathoracic pressure excursions. When used with other clinical variables, PVi® may help clinicians assess fluid responsiveness in surgical and intensive care patients who are mechanically ventilated and help determine other treatment options. PVi® has received FDA 510(k) clearance as a continuous, noninvasive, dynamic indicator of fluid responsiveness in select populations of mechanically ventilated adult patients.
RPVi
Rainbow® Pleth Variability Index (RPVi) is a multi-wavelength version of PVi® that is designed to provide enhanced specificity to changes in fluid volume compared to PVi®. Similar to PVi®, RPVi is displayed as a percentage and is calculated by measuring changes in Pi over a time interval where one or more complete respiratory cycles have occurred. The lower the number, the less variability there is in Pi over a respiratory cycle, which indicates more fluid in the body. RPVi has received the CE Mark, but is not currently available for sale in the U.S.
RRp®
Respiration rate is defined as the number of breaths per minute. Changes in respiration rate provide an early warning sign of deterioration in patient condition. A low respiration rate is indicative of respiratory depression and high respiration rate is indicative of patient distress. Current methods of monitoring respiration rate include end tidal carbon dioxide (EtCO2) monitoring, which requires a nasal cannula be inserted in the patient’s nose or a mask to be worn, and therefore has low patient compliance; and impedance monitoring, which is considered unreliable and requires the placement of ECG electrodes on the chest. RRp® allows clinicians to noninvasively and continuously measure and monitor respiration rate using a standard Masimo SET® pulse oximetry sensor or rainbow® Pulse CO-Oximetry sensor. RRp® is determined by the variations in the plethysmograph waveform due to respiration, although the measurement is not possible in all patients or conditions and may not immediately indicate changes in respiration rate. RRp® has received the CE Mark, as well as FDA 510(k) clearance when used in healthcare settings with the MightySat® Rx fingertip SET® pulse oximeter. RRp® is also available in the U.S. for use by consumers for general health and wellness purposes as part of our MightySat® fingertip pulse oximeter. RRp® has received FDA 510(k) clearance for continuous RRp® monitoring of adult and pediatric patients with Rad-97®, Radical-7® and Radius-7® Pulse Co-Oximeters®. With this clearance, both continuous and spot-check RRp® are now available in the U.S. and supported in a variety of pulse oximetry sensors and configurations, including a non-cabled, tetherless, wearable Radius PPG.

5

Table of Contents

RRa®
Our sound-based monitoring technology, rainbow Acoustic Monitoring® (RAM®), enables RRa® and provides continuous and noninvasive monitoring of respiration rate. For patients requiring accurate and sensitive respiration rate monitoring, we believe that RRa® better detects pauses in breathing than respiration rate measurements from other technologies such as EtCO2 monitoring and RRp®. RRa® also provides an important visual indication of breathing through a displayed acoustic waveform.
Multiple clinical studies have shown that the noninvasive measurement of acoustic respiration rate provides as good or better respiration rate monitoring accuracy as EtCO2 monitoring, and can reliably detect episodes of respiratory pause, defined as the cessation of breathing for 30 seconds or more. When used with other clinical variables, RRa® may help clinicians assess respiratory depression and respiratory distress earlier and more often to help determine treatment options and potentially enable earlier interventions.
SpfO2
Prior to our debut of SpfO2, pulse oximeters could only measure and display functional SpO2 oxygen saturation. Therefore, when patients had elevated carboxyhemoglobin and/or elevated methemoglobin, the displayed functional SpO2 oxygen saturation overestimated the actual oxygen saturation value. SpfO2, or fractional oxygen saturation, allows more precise arterial oxygenation assessment in patients with elevated dyshemoglobins, common throughout the hospital and pre-hospital setting, compared to functional oxygen saturation, and may also allow earlier interventions and more timely therapeutic decisions. SpfO2 has received the CE Mark, but is not currently available for sale in the U.S.
ORi
ORi provides real-time visibility to oxygenation status in moderate hyperoxic range, which we define as a patient’s oxygen “reserve”. ORi can be trended and has optional alarms to notify clinicians of changes in a patient’s oxygen reserve. When this technology is used with SpO2 monitoring, ORi may extend the continuous and noninvasive visibility of a patient’s oxygen status into ranges previously unmonitored in this fashion. ORi may also be of value in patients receiving supplemental oxygen, such as those in surgery, under conscious sedation or in the ICU, as ORi is represented as an “index” parameter with a unit-less scale between 0.00 and 1.00. Furthermore, ORi may provide an advance warning of an impending hypoxic state, or an indication of an unintended hyperoxic state, when evaluated in conjunction with the partial pressure of oxygen (PaO2). In this way, ORi may assist in determining the need for proactive interventions to avoid hypoxia or unintended hyperoxia. ORi has received the CE Mark, but is not currently available for sale in the U.S.
Other Noninvasive Measurements
Following the introduction of our rainbow SET® platform, we have continued to expand our technology offerings by introducing additional noninvasive measurements and technologies to create new market opportunities in both hospital and non-hospital care settings.
SedLine® Brain Function Monitoring
Brain function monitoring is most commonly used during surgery to help clinicians avoid over-titration and under-titration of anesthesia and sedation. SedLine® brain function monitoring technology measures the brain’s electrical activity by detecting EEG signals. In contrast to whole-scalp EEG monitoring, which is used for diagnostic purposes, this form of EEG monitoring is often referred to as processed EEG monitoring or brain function monitoring. Brain function monitors display the patient’s EEG waveforms, but these may be difficult for clinicians to interpret. With SedLine® technology, EEG signals are processed and displayed as a single number called the Patient State Index (PSi), which gives a continuous quantitative indication of the patient’s depth of anesthesia and sedation. SedLine® brain function monitoring technology also displays raw EEG waveforms, the PSi trend and a Density Spectral Array view, which allows clinicians to compare EEG power in both sides of the brain over time to facilitate the detection of asymmetrical activity and agent-specific effects on the EEG signal.
SedLine® brain function monitoring technology is available on Root® through the use of a Masimo Open Connect® (MOC-9®) connectivity port. The Root® patient monitoring and connectivity platform integrates rainbow® and SET® measurements with measurement technologies, such as SedLine®.
NomoLine® Capnography and Gas Monitoring
We offer a portfolio of capnography and gas monitoring products ranging from external “plug-in-and-measure” capnography and gas analyzers, integrated modules, handheld capnograph and capnometer devices and capnography sampling lines. Our NomoLine® capnography sampling lines are available in more than 40 configurations of airway adapter sets and cannulas for use in a variety of clinical scenarios on both intubated and non-intubated adult, pediatric, infant and neonatal patients, in both low and high humidity configurations, facilitating easy to use sidestream capnography and gas monitoring.
6

Table of Contents

These products have the ability to measure multiple expired gases, such as carbon dioxide (CO2), nitrous oxide (N2O), oxygen (O2) and other anesthetic agents. In addition, respiration rate is calculated from the CO2 waveform. These measurements are possible through either mainstream monitoring, which samples gases from a ventilated patient’s breathing circuit, or sidestream monitoring, which samples gases from a breathing circuit in mechanically ventilated patients or through a cannula or mask in spontaneously breathing patients. These capnography and gas measurements are standard-of-care in many hospital environments, such as operating rooms and ICUs, during procedural sedation. NomoLine® capnography sampling lines have received FDA 510(k) clearance.
O3® Organ Oximetry
O3® organ or Regional Oximetry, also known as tissue or cerebral oximetry, uses near-infrared spectroscopy (NIRS) to provide continuous measurement of tissue oxygen saturation (rSO2) to help detect regional hypoxemia, or oxygen deficits in specific tissues such as the brain, that pulse oximetry alone cannot detect under certain conditions. In addition, O3® sensors, in conjunction with our Root® monitor, can automate the differential analysis of regional to central oxygen saturation derived from SET® pulse oximeters. O3® monitoring involves applying O3® Regional Oximetry sensors to the forehead and connecting the O3® MOC-9® module to a Root® monitor through one of its three MOC-9® ports. O3® Regional Oximetry has received the CE Mark and FDA 510(k) clearance for use in adult and pediatric patients, including use of O3® in infant and neonatal patients, as well as expanded use in monitoring somatic tissue oxygenation saturation in all patient populations and monitoring relative changes in hemoglobin, oxyhemoglobin and deoxyhemoglobin in adult brains.
Advanced Hemodynamic Monitoring Solutions
In January 2021, we acquired LiDCO Group, PLC, which specializes in advanced hemodynamic monitoring solutions. With the completion of this acquisition, we will be able to provide clinicians with access to patients’ cardiac output (CO), stroke volume (SV), systemic vascular resistance (SVR), oxygen delivery (DO2), stroke volume variation (SVV) and pulse pressure variation (PPV), which are used to assess preload and afterload, to help determine the current state of a patient’s hemodynamic stability and whether any interventions are needed to optimize the delivery of oxygen to the tissues. Hemodynamic monitoring solutions are also used to monitor the response to therapies such as vasopressors, inotropes and fluids.
The Masimo Hospital AutomationTM Platform
Patient SafetyNet™(1)
Patient SafetyNet, our patient surveillance, remote monitoring and clinician notification solution, works in concert with our bedside and ambulatory monitoring devices to facilitate the supplemental monitoring of the oxygen saturation, pulse rate, perfusion index, hemoglobin, methemoglobin and respiration rate of up to 200 patients simultaneously from a single server. Patient SafetyNet offers an intuitive and powerful user interface with trending, real-time waveform capability at a central station, as well as remote clinician notification via pager, voice-over-IP phone or smart-phones. Patient SafetyNet also features an Adaptive Connectivity Engine(ACE) that enables two-way, HL-7 based connectivity to clinical/hospital information systems. The ACE significantly reduces the time and complexity to integrate and validate custom HL-7 implementations, and demonstrates our commitment to innovation that automates patient care with open, scalable and standards-based connectivity architecture.
Patient SafetyNet Series 5000, along with Hospital Automation Connectivity, Iris® Gateway, Kite®, UniView, UniView : 60™, and MyView® through the Root® patient monitoring and connectivity platform, offers a new level of interoperability designed to enhance clinician workflows and reduce the cost of care in a variety of hospital settings, including operating rooms and the general care floors. Patient SafetyNet Series 5000 with Iris® ports enables Root® to assimilate data from all devices connected to the patient, thereby acting as a comprehensive in-room patient monitor and connectivity hub. Alarms and alerts for all devices are seamlessly forwarded to the patient’s clinician and device data can be transferred to the patient’s electronic medical record (EMR). The patient-centric user interface of the Patient SafetyNet Series 5000 displays near real-time data from all devices with Kite®, providing a single unified dashboard of patient information. To simplify documentation of patient data, Root® enables clinicians to easily verify and send patient vitals and Early Warning Scores (EWS), as well as all connected medical device information data, to the EMR directly from Root®.
An interface between the Patient SafetyNet Series 5000 and the hospital admission, discharge and transfer (ADT) system allows clinicians to receive ADT information on Root® for positive patient identification at the bedside. Clinicians can also manually enter additional data on the Root® device, including temperature, blood pressure, level of consciousness, pain score and urine output.
______________
(1) The use of the trademark Patient SafetyNet is under license from the University HealthSystem Consortium.
7

Table of Contents

In a series of studies published between 2010 and 2020 by Dartmouth-Hitchcock Medical Center, clinicians using Masimo SET® and Patient SafetyNet identified patient distress earlier, which decreased rapid response team activations, ICU transfers and ICU days. Per these studies, over ten years, there were zero preventable deaths or brain damage due to opioid-induced respiratory depression in monitored patients. In addition, we believe these studies demonstrated that the use of Masimo SET® and Patient SafetyNet can result in significant cost savings. Hospitals and other care centers may determine that they can reduce their costs by moving less critically ill patients from the ICU to the general care floors where they can be continuously and accurately monitored in a more cost-effective manner. We believe that the advanced performance of the Masimo SET® platform coupled with reliable, cost-effective and easy-to-use wireless remote monitoring will allow hospitals to create continuous surveillance solutions on general care floors where patients are at risk of avoidable adverse events and where direct patient observation by skilled clinicians is considered cost prohibitive.
Kite®
Kite® provides a supplemental display of data from a Masimo device on a compatible smart television and allows clinicians to configure the display differently than that of the connected Masimo device. Kite® integrates into existing hospital infrastructures where a supplementary display may be beneficial, such as the operating room.
UniView
UniView, an integrated display of real-time data and alarms from multiple Masimo and third-party devices, designed to reduce clinician cognitive overload and improve patient safety. UniView promotes data sharing and team coordination among multiple clinicians. UniView brings together data from a variety of sources – such as patient monitors, ventilators, anesthesia gas machines, and IV pumps – and provides a supplementary display for them, clearly organized, on one or more large, central monitors, so that all clinicians can simultaneously view and act upon the same, comprehensive real-time patient status and historical trends.
UniView : 60
UniView : 60 uses the Masimo Hospital Automation platform to aggregate and display pertinent patient information on a digital display just outside each patient’s room, allowing clinicians to familiarize themselves with the most relevant details of each patient’s case at the door in 60 seconds or less before they see the patient.
Replica
Replica, working in conjunction with Patient SafetyNet, is a mobile application for smart phones and tablets that provides for supplemental remote monitoring and clinician notification. Replica was developed to allow clinicians to view continuous monitoring data for multiple patients, as well as view and respond to alarms and alerts, all from their smart phones, regardless of location.
MyView®
MyView® is a wireless, presence-detection system that enables the display of customized clinical profiles on Masimo devices, such as Root®, Radical-7® and the Patient SafetyNet View Station. When a clinician approaches the device, a clinician-worn MyView® badge signals the device to display a preselected set of parameters and waveforms tailored to the individual clinician’s preferences. MyView® gives clinicians the ability to receive and review medical device information in a manner that is most conducive to optimizing their workflow, while the presence mapping data collected by all the Masimo devices can provide insight into how clinicians spend time with patients. This provides nursing leadership and management the opportunity to examine analytical data on patient-clinician interactions and optimize workflows across the unit, hospital and hospital system.
Patient SafetyNet Surveillance
Patient SafetyNet Surveillance is a software option that provides real-time video images of a patient’s room, including the patient and connected monitoring devices, adding existing communication technology to central monitoring. Two-way audio is available to allow the caregiver to listen to and communicate with the patient. The system utilizes the existing hospital information technology network, precluding the installation of additional infrastructure.

8

Table of Contents

Connectivity
Despite medical technology advances, the lack of device communication and integration creates risks to patient safety in hospitals around the world. Without device interoperability, critical patient information can go unnoticed, leaving clinicians unaware and patients at risk. Existing approaches for device interoperability require separate hardware, software and/or network infrastructure, which can clutter the patient room, increase complexity, burden IT management and increase costs. To address these challenges, we introduced Iris® connectivity in our Root® patient monitoring and connectivity platform. Iris® connectivity enables multiple standalone third-party devices such as intravenous pumps (IV), ventilators, hospital beds and other patient monitors to connect through Root®, enabling display, notification and documentation to the EMR through Masimo Patient SafetyNet.
The addition of Iris® connectivity to Root® and Patient SafetyNet provides multiple advantages to hospitals, such as allowing standalone device information to be remotely viewed at a Patient SafetyNet view station, transmitted through notification systems to clinicians regardless of location or sent to electronic health record systems. This may enhance patient assessment, clinical workflows and decision support. In addition, bringing data from disparate devices together facilitates more integrated patient care and provides a flexible and cost-effective platform, while avoiding installation of separate costly systems and potentially reducing costs by leveraging existing network infrastructure.
Nasal High-Flow Ventilation
The Masimo softFlow technology provides respiratory support by generating a precisely regulated, stable and high flow of room air or a mix of room air and oxygen through the nose of the patient by means of thin nasal prongs. Controlled oxygen supply ensures oxygenation while, at the same time, the respiratory airways are humidified. A stable air flow is essential for treating hypoxemic and hypercapnic respiratory failure. Together with the softflow nasal applicator, the softflow generator provides a constant air flow and in doing so, it is completely independent of external pneumatic systems. Due to this, the Masimo softFlow technology is able to treat respiratory insufficiency and allows therapy at home in a manner that is as reliable and efficient as in the hospital.
Neuromodulation Solution
Bridge is the first FDA-cleared, drug-free, non-surgical device to use neuromodulation to aid in the reduction of symptoms associated with opioid withdrawal. Bridge can be used for patients experiencing opioid withdrawal symptoms, while undergoing treatment for opioid use disorder when initiating treatment, transitioning to naltrexone or tapering off medication-assisted treatment. In addition, we believe Bridge may reduce pain and addiction-related side-effects. Bridge is a small electrical nerve stimulator device that contains a battery-powered chip and wires that are applied percutaneously around a patient’s ear. It requires a prescription and is offered to qualified healthcare professionals with training. Bridge has been granted a FDA 510(k) de novo classification.
Coronavirus-2019 (COVID-19) Response and Telehealth Solutions
Masimo SafetyNet
In an effort to help clinicians and public health officials combat the COVID-19 pandemic, we developed the Masimo SafetyNet solution. The Masimo SafetyNet solution provides continuous tetherless pulse oximetry and respiration rate monitoring coupled with a patient surveillance platform. Masimo SafetyNet solution is available worldwide. In partnership with Samsung Electronics America (Samsung), the Masimo SafetyNet Patient App is available on select Samsung smartphones, pre-installed and pre-configured.
Masimo SafetyNet-OPEN
As the COVID-19 pandemic continues, companies and organizations worldwide struggle to find the appropriate balance between reopening and keeping people safe by reducing the risk of infection. Masimo SafetyNet-OPEN was designed to help businesses, governments and schools more responsibly manage employee and student health and safety during the COVID-19 pandemic. Masimo SafetyNet-OPEN helps address certain challenges of reopening responsibly and safely with a comprehensive, flexible, and easy-to-deploy continuous monitoring solution that, in conjunction with clinical guidance from partner hospitals, helps manage prevention, early identification, and recovery monitoring. As a global leader in noninvasive patient monitoring technologies and advanced connectivity and automation solutions, we believe we are uniquely positioned to provide organizations with tools to assist them in reopening safely.




9

Table of Contents

Recent Developments
On February 15, 2022, we announced our entry into a definitive merger agreement to acquire Viper Holdings Corporation, which owns Sound United (“Sound United”), a consumer technology company that owns a portfolio of premium brands, including Bowers & Wilkins, Denon, Polk Audio and Marantz. Pursuant to the merger agreement, we will pay approximately $1.025 billion, subject to adjustments, for the acquisition. The transaction is subject to customary closing conditions and is expected to close in the middle of 2022.
Our Strategy
Our mission is to develop technologies that improve patient outcomes and reduce the cost of patient care. We intend to continue to grow our impact on patient care by not only providing patient-centered solutions to healthcare providers, but by also expanding outside of the hospital arena with our technologies that are improving lives in the hospitals. We believe that people and infrastructures are ready for actionable patient care outside of the hospital. Some of our tactics are explained below:
Continue to Expand our Market Share in Pulse Oximetry. We grew our product revenue to $1,239.2 million in 2021 from $829.9 million in 2018, representing a three-year compound annual growth rate of 14.3%. This growth can be attributed to continued expansion of our core SET® pulse oximeter customer base, higher revenues from rainbow® Pulse CO-Oximetry, NomoLine® capnography and other new technologies, and our expanding list of OEM partners. We supplement our direct sales to hospitals and other low-acuity healthcare facilities through various U.S. and international distributors. Combined sales through our direct and distributor sales channels increased to $1,099.1 million, or 88.7% of product revenue in 2021, from $718.6 million, or 86.6% of product revenue, in 2018. As the healthcare industry shifts toward hospitals, physicians and providers being rewarded by payers based on the quality and value of the services (as opposed to the volume of fee-for-service transactions), we expect to see more hospitals gravitate towards technologies like Masimo SET® that have a proven track record of improving patient care.
Expand the Pulse Oximetry Market to Other Patient Care Settings. Many patients die due to unintended opioid overdoses after surgery while on general care floors. We believe the ability to continuously and accurately monitor patients outside of critical care settings, including the general, medical and surgical floors of the hospital, is currently an unmet medical need that has the potential to significantly improve patient care and increase the size of the pulse oximetry market. In addition, we believe the ability of Masimo SET® to accurately monitor and address the limitations of conventional pulse oximetry has enabled us, and will continue to enable us, to expand into non-critical care settings, and therefore, significantly expand the market for our products. To further support our expansion into the general care areas, we market Patient SafetyNet, which enables continuous monitoring of up to 200 patients’ SpO2, PR, RRp® and with rainbow SET®, noninvasive monitoring of hemoglobin and other advanced measurements. We believe that Patient SafetyNet, when combined with Masimo SET® pulse oximetry and RAM® or capnography, offers a clinically proven and cost-effective approach to continuous post-operative monitoring. Outside of the hospital setting, patients could die due to unintentional opioid overdose, even when opioids are being taken for short duration, such as after surgery, and as prescribed by a physician.
Expand the Use of rainbow® Technology in Hospital Settings. We believe the noninvasive measurements of rainbow® Pulse CO-Oximetry (SpHb®, SpCO®, SpMet®, PVi®, SpfO2, SpOC and ORi), RAM® and Halo Ion®, as well as future measurements, provide an excellent opportunity to help our customers improve patient care while reducing their overall cost of care.
Expand the Use of rainbow® Technology in Non-Hospital Settings. We believe the noninvasive measurement of hemoglobin, SpHb®, creates a significant opportunity in markets such as physician offices, emergency departments and blood donation centers; and the noninvasive measurement of carboxyhemoglobin, SpCO®, creates a significant opportunity in the fire/alternate care market.
Expand the Use of Root® in Hospital Settings. We believe Root® represents a powerful paradigm in patient monitoring because it enhances our rainbow® and SET® measurements with multiple specialty parameters, including SedLine® brain function monitoring, O3® Regional Oximetry, and NomoLine® capnography and gas monitoring, and enables open-architecture connectivity in an integrated, clinician-centric hub. Our Hospital Automation integration platform for Root® provides a conduit to the patient’s EMR for a range of clinical devices that may otherwise remain disconnected, and therefore, unable to communicate their information. Hospital Automation, in conjunction with the Iris® ports found on Root®, offers clinical utility and flexibility by collecting device information from multiple sources and making it available to clinicians in one networked place, akin to an airplane cockpit. Complementary innovations like the Radius-7® wearable, wireless monitor foster an environment of safety without sacrificing patient mobility or comfort. Radius-7® provides patients in medical-surgical units with mobility, allowing them to visit common areas and labs, all while being continuously monitored around the clock. Root® is acuity-adaptable, meaning it can be configured for any care area, and is competitively priced.
Expand Hospital Automation and Connectivity in Hospital Settings. We believe we can improve and automate the continuum of care through our connectivity platform by reducing complexity by integrating data from multiple disparate monitors and therapeutic devices through Root® and Iris® Gateway; by deploying decision support algorithms like Halo
10

Table of Contents

ION®; by saving time through semi-automated and automated bedside vital signs measurement and documentation with Patient SafetyNet; by keeping patients connected with their care providers through Masimo SafetyNet and Rad 97® when they are discharged from hospitals; by improving data interpretation through adaptable and intuitive displays like UniView, UniView : 60 and MyView®; and through remote monitoring via Patient SafetyNet and Replica.
Utilize our Customer Base and OEM Relationships to Market Masimo rainbow SET®, O3®, SedLine® and Capnography Products Incorporating Licensed rainbow® Technology. We currently sell rainbow SET® products through our direct sales force and distributors. We include our MX circuit boards in our pulse oximeters and also sell them to our OEM partners. Our MX circuit boards are equipped with circuitry to support rainbow® Pulse CO-Oximetry measurements that can be activated at time of sale or through a subsequent software upgrade. We believe that, over time, the clinical need for these measurements, along with our installed customer base, will help drive the adoption of our rainbow® Pulse CO-Oximetry products.
Continue to Innovate and Maintain Our Technology Leadership Position. We invented and pioneered the first pulse oximeter to accurately measure arterial blood oxygen saturation level and pulse rate in the presence of motion artifact and low perfusion. In addition, we launched our rainbow SET® platform that enabled what we believe is the first noninvasive monitoring of carboxyhemoglobin, methemoglobin and hemoglobin, as well as PVi®, all of which were previously only available with invasive and/or complicated testing. Furthermore, we believe that our introduction of RRa® with RAM® technology represented the first platform to enable noninvasive and continuous respiration monitoring through an easy-to-use single-patient adhesive acoustic sensor. Finally, we believe that our recent introduction of ORi may provide advance warning of an impending hypoxic state, or an indication of an unintended hyperoxic state.
Expand Masimo technology into the personal health consumer and home market. Our first general wellness and personal health consumer and home market application was the MightySat®, a fingertip pulse oximeter with five important health and breathing measurements that was targeted at sports, fitness and relaxation. These values include: O2, PR, RRp®, PI and PVI®. In the past two years, we launched six additional products for the consumer and home market. We released the Radius T°, a means to monitor a loved one’s fever in a hassle-free continuous manner; Masimo Sleep, a means to help you understand what is going on in your body that may be impacting your sleep; Bridge, the first FDA-cleared, drug-free, non-surgical device to use neuromodulation to aid in the reduction of symptoms associated with opioid withdrawal; Masimo Doctella, a secure, cloud-based platform that allows providers to customize interactive digital CarePrograms for their patients from the hospital to the home by helping them view patient inputs and compliance with treatment plans, interpret physiological data, and collect population health data; SafetyNet-OPEN, a remote patient management solution for tracking key vital signs at the organizational level; and finally, SafetyNet-Alert, a remote patient management solution for tracking key vital signs at home. We believe that in the home setting, accurate monitoring with Masimo SET® and Masimo SafetyNet Alert may help reduce the risk of opioid overdose by alerting family members and others when opioids have slowed a patient’s breathing and caused a significant drop in oxygen saturation.
Expand the Masimo product portfolio through strategic investments and acquisitions. In 2020 and 2021, we successfully completed three strategic acquisitions and an exclusive license agreement, all of which are currently being integrated into our product portfolio. In addition, on February 15, 2022, we announced our entry into a definitive merger agreement to acquire Sound United, a consumer technology company that owns a portfolio of premium brands. We continually evaluate new and exciting opportunities to expand our product portfolio. We pursue the opportunities that we believe will add stockholder value, can be successfully integrated within our business and show positive potential to achieve our business and financial objectives.
We plan to continue to innovate and develop new technologies and products, internally and through our collaboration with Cercacor, from whom we currently license certain rainbow® technologies.
Our future growth strategy is also closely tied to our focus on international expansion opportunities. Since 2007, we have continued to expand our sales and marketing presence in Europe, Asia, Asia Pacific, Middle East, Canada and Latin America. We have accomplished this by both additional staffing and adding or expanding sales offices in many of these territories. By centralizing a portion of our international operations, including sales management, marketing, customer support, planning, logistics and administrative functions, in Neuchâtel, Switzerland, we believe we have developed a more efficient and scalable international organization that is capable of being even more responsive to the business needs of our international customers under this centralized management structure.
Our Products and Markets
We develop, manufacture and market patient monitoring technologies that incorporate a monitor or circuit board and sensors, including proprietary single-patient-use and reusable sensors and patient cables. In addition, we offer remote alarm/monitoring solutions, software and connectivity solutions.
The following chart summarizes our principal product components and principal markets and methods of distribution:
11

Table of Contents


Patient Monitoring Solutions:
Description:
Use:
Distribution Channel:
Circuit Boards and Modules
(e.g., MX-5, MX-7, MSX (shown below), MS-2011, MS-2013, MS-2040, uSpO2®, SedLine®, ISA and IRMA)
• Signal processing apparatus for all Masimo technology platforms

• Mainstream and sidestream capnography and gas monitoring
• Incorporated and sold to OEM partners who incorporate our circuit boards into their patient monitoring systems
Monitors and Devices
(e.g., Radical-7®, Rad-97® (both shown below), Rad-67®, Rad-57®, Root®, Rad-8®, Rad-5®, Radius-7®, Rad-G™, and TIR-1™,)
• Bedside, handheld and wireless monitoring devices that incorporate Masimo SET® with and without licensed Masimo rainbow SET® technology, noninvasive blood pressure and capnography.
• Sold directly to end-users and through distributors and in some cases to our OEM partners who sell to end-users
12

Table of Contents

Description:
Use:
Distribution Channel:
Patient Monitoring and Connectivity Platform
(e.g., Root®, Radius-7® and Root® with NIBP (shown below))
• Displays measurements from Masimo’s Radical-7® (connected or hand carried) or Radius-7® (patient-worn)

• Provides additional specialty measurements from Masimo or third-party-developed applications through Masimo Open Connect® (MOC-9®)

• Integrates noninvasive blood pressure (NIBP) and temperature

• Connects third-party devices such as IV pumps, ventilators, beds and other patient monitors to automate data transfer to the EMR

• Sold directly to end-users and through distributors
Sensors
(e.g., SET®, rainbow® Pulse CO-Oximetry, rainbow Acoustic Monitoring® Sensors, RD SedLine, TFA-1®, RD SET®, RD rainbow SET®, O3® Pediatric, RD rainbow Lite SET®, rainbow® DCI®-Mini, Centroid and Radius PPG (last six shown below))
• Extensive line of both single-patient, reusable and rainbow® sensors

• Patient cables, as well as adapter cables that enable the use of our sensors on certain competitors’ monitors
• Sold directly to end-users and through distributors and to OEM partners who sell to end-users
13

Table of Contents

Description:
Use:
Distribution Channel:
Sensors (Continued)
Line Filters and Mainstream Adapters for Capnography and Gas Monitoring
(e.g., NomoLine® Cannula with Radius PCG Capnograph with disposable adapter, IRMA CO2, IRMA AX+ and EMMA® (shown below))
• Line of disposables to measure gas parameters using mainstream and sidestream capnography

• Sold directly to end-users and through distributors and to OEM partners who sell to end-users
Proprietary Measurements
(e.g., SpHb
®, SpCO®, SpMet®, PVi®, RRa®, RRp®, ORi, 3D Alarms® and Adaptive Threshold Alarm)
• rainbow® measurements and other proprietary features
• Sold directly to end-users and through OEM partners who sell to new and existing end-users
14

Table of Contents

Description:
Use:
Distribution Channel:
Hospital Automation and Connectivity Suite
(e.g., Iris
® Connectivity, Iris® Gateway, iSirona, Patient SafetyNet, UniView, and UniView : 60, Replica, Iris® Analytics, and Halo ION® (shown below))
• Software and hardware enabling third-party devices to connect through Patient SafetyNet and to document data in the EMR
• Sold directly to end-users
15

Table of Contents

Description:
Use:
Distribution Channel:
Hospital Automation and Connectivity Suite (Continued)
• Network-linked, wired or wireless, multiple patient floor monitoring solutions

• Standalone wireless alarm notification solutions
• Sold directly to end-users
• Home-based patient engagement and remote data capture platform
• Sold directly to end-users and through distributors

• Connectivity hub for the aggregation and transmission of patient data to the EMR• Sold directly to end-users
Nasal High Flow Ventilation
(e.g., TNI softFlow® 50 and TNI softFlow® junior(shown below))
• Intensive care and inpatient care in clinics as well as home care
• Sold directly to end-users and through distributors

16

Table of Contents

Description:
Use:
Distribution Channel:
Nasal High Flow Ventilation (Continued)
Advanced Hemodynamic Monitoring Solutions
(e.g., Masimo LiDCO Hemodynamic Monitoring system, Double Channel Pressure Transducer and Stimpod NMS450X Peripheral Nerve Stimulator(shown below))
• High-acuity care areas such as the operating room• Sold directly to end-users and through distributors
Home Wellness and Monitoring
(e.g., Radius T°, Masimo Sleep, MightySat® with PVi® and RRp® and iSpO2®)
• Disposable thermometers, disposable fingertip sensors for sleep monitoring, fingertip pulse oximeter, or pulse oximeter cable and sensor for use with an iPhone, iPad, iPod touch and select Android smart phones• Sold directly to consumers through the Masimo Personal Health website and through consumer retailers
17

Table of Contents

Description:
Use:
Distribution Channel:
Home Wellness and Monitoring (Continued)
Circuit Boards
Masimo SET® MS Circuit Boards. Our Masimo SET® MS circuit boards perform all signal processing and other pulse oximetry functions incorporating the Masimo SET® platform. Our MS circuit boards are included in our proprietary monitors or sold to our OEM partners for incorporation into their monitors. Once incorporated into a pulse oximeter, the MS circuit boards perform all data acquisition processing and report the pulse oximetry measurements to the host monitor. The circuit boards and related software interface directly with our proprietary sensors to calculate SpO2, PR and Pi. Our latest MSX family of circuit boards provide Masimo SET® SpO2, PR, and Pi in a variety of small form factors with a typical power consumption of only 45 milliwatts.
uSpO2® Cable/Board. Our SET® technology-in-a-cable contains the low power (MS-2040) technology in a reduced size, allowing it to be embedded into patient cables as part of the sensor connector. This allows the uSpO2® cable/board to interface with monitoring devices externally via an existing communications port in instances where internal integration of a traditional Masimo SET® technology board is not feasible. The uSpO2® cable/board provides the same Masimo SET® Measure-through Motion and Low Perfusion pulse oximetry found in our other products, with a typical power consumption of less than 45 milliwatts.
Masimo rainbow SET® MX Circuit Boards. Our circuit board is the foundation for our Masimo rainbow® Pulse CO-Oximetry and rainbow Acoustic Monitoring® platform, utilizing certain technology that is licensed from Cercacor. The MX circuit boards offer the full functionality of our rainbow® technology, which includes noninvasive measurements for SpHb®, SpOC, SpCO®, SpMet®, PVi® and RRa®, in addition to providing Measure-through Motion and Low Perfusion SET® pulse oximetry measurements SpO2, PR and Pi measurement capabilities of Masimo SET® pulse oximetry. Customers can choose to purchase additional measurements beyond SpO2, PR and Pi at the time of sale or at any time in the future through a field-installed software upgrade.
Our MX-5 OEM circuit board deploys a technology platform that utilizes approximately half the power of previously available rainbow® circuit boards to deliver rainbow® Pulse CO-Oximetry noninvasive measurement performance. In addition to its lower power demands, the MX-5 adds dynamic power utilization to scale the MX-5’s power draw based upon the combination of parameters being monitored to permit even longer battery run-times.
18

Table of Contents

Our MX-7 OEM circuit board is our latest and most advanced rainbow SET® board. The MX-7 board builds on the current MSX low-power SET® board and MX-5 rainbow® board technologies by offering more efficient power utilization, scaling its power draw based upon the combination of rainbow SET® parameters being monitored to permit even longer battery run times. Designed for integration into the more than 200 multi-parameter monitors available from our more than 90 OEM partners, the MX-7 has the ability to support all 13 of Masimo’s SET® pulse oximetry and rainbow® Pulse CO-Oximetry measurements in an advanced module re-engineered to reduce power needs.
Monitors / Devices
Root®. Root® is a powerful patient monitoring and connectivity platform that integrates our rainbow® and SET® measurements with multiple additional specialty measurements through MOC-9® open architecture technology in an integrated, clinician-centric platform. The first MOC-9® technologies developed by Masimo were SedLine® brain function monitoring, NomoLine® capnography and gas monitoring and O3® Regional Oximetry. Root® with NomoLine® capnography, SedLine® brain function monitoring, wireless communication and Iris® connectivity for third-party medical devices has received FDA 510(k) clearance. O3® Regional Oximetry has received the CE Mark and FDA 510(k) clearance.
Early Warning Signs (EWS) for Root® aggregates information from multiple vital signs and clinical observations to generate a score that represents the potential degree of patient deterioration. There are several EWS protocols, such as the Pediatric Early Warning Score (PEWS), Modified Early Warning Score (MEWS) and National Early Warning Score (NEWS). These various scores require vital signs contributors such as oxygen saturation, pulse rate, respiration rate, body temperature and systolic blood pressure along with contributors input by clinicians, such as level of consciousness, use of supplemental oxygen and urine output. The weighting and number of contributors differ depending upon which EWS protocol is used. Root® can be customized for various predefined EWS protocols, or hospitals can configure their own set of required contributors, and their relative weights, to create an EWS unique to their care environment.
Our MOC-9® partnerships enable third parties to utilize Root®’s open architecture and built-in connectivity to independently develop, obtain regulatory approvals, and commercialize their own external MOC-9® module. Alternatively, third parties can develop Masimo Open Connect Control (MOC-C) applications for Root® using the MOC-9® software development kit (SDK). While we support the development efforts of our MOC® partners as needed, and help increase awareness of the availability of non-Masimo MOC-9® modules and MOC-C applications, our MOC-9® partners use their existing distribution channels to sell their MOC-9® modules or MOC-C applications to customers.
Pathway, a newborn oxygenation visualization mode for Root®, provides clinicians with a way to visualize a hospital’s recommended resuscitation protocol for a newborn’s oxygen saturation while continuously monitoring SpO2 and PR during the first ten minutes after birth. Use of Pathway is intended to help streamline clinician workflow and improve protocol adherence during this critical period.
Radical-7®. The Radical-7® Pulse CO-Oximeter® is a wireless touchscreen device that incorporates our MX circuit board to allow upgradeable rainbow SET® measurements and offers three-in-one capability. The Radical-7® can be used as:
a standalone device for bedside monitoring;
a detachable, battery-operated handheld unit for easy portable monitoring;
an integrated device as part of the Root® patient monitoring and connectivity platform; and
a monitor interface via SatShare®, a proprietary technology allowing our products to work with certain competitor products, to upgrade existing conventional multiparameter patient monitors to Masimo SET® while displaying rainbow® measurements on the Radical-7® itself.
With its wide-ranging flexibility, Radical-7® can continuously monitor a patient from the ambulance, to the emergency room, to the operating room, to the general floor and beyond, until the patient is discharged. Radical-7® delivers the accuracy and reliability of Masimo rainbow SET® with multi-functionality, ease of use and the availability of measurement upgrades for existing monitors.
Radius-7®. Radius-7® for the Root® patient monitoring and connectivity platform is the first and only wearable, wireless monitor with rainbow SET® technology, enabling continuous monitoring and early identification of clinical deterioration while still allowing patients the freedom of movement. With Bluetooth® and Wi-Fi wireless connectivity, Radius-7® with Root® can alert clinicians at the bedside or remotely, through Masimo Patient SafetyNet, of critical changes in a patient’s SpO2 and PR, even during states of motion and low perfusion, as well as RRa® and additional rainbow SET® measurements. Radius-7® with Root® has received both the CE Mark and FDA 510(k) clearance.
19

Table of Contents

Radius PPG. Radius PPG is a tetherless sensor solution powered by Masimo SET® that represents a significant breakthrough in patient monitoring. Radius PPG eliminates the need for a cabled connection to a pulse oximetry monitor, allowing patients to move freely and comfortably while still being continuously monitored reliably and accurately. Via wireless connection, measurements are displayed on Masimo host devices or third-party multi-parameter monitors with integrated Masimo technology. Coupled with the proven benefits of Masimo SET® Measure-through Motion and Low Perfusion pulse oximetry, Radius PPG is ideally suited for use anywhere patients can benefit from mobility. Radius PPG is also available as part of the Masimo SafetyNet remote patient management solution designed for at home use.
Radius VSM. Radius VSM is a wearable, tetherless vital signs monitor that provides the ability to monitor a wide variety of physiological measurements, including continuous SET® Pulse Oximetry, noninvasive blood pressure, body temperature, respiration rate and ECG. Designed on a wearable, modular platform, Radius VSM features can be scaled to accommodate surges in patient volume and for use across the continuum of patient care, based upon each patient’s needs and level of acuity. For additional versatility, Radius VSM can operate as a self-contained device or be used wirelessly with Masimo bedside monitors and patient surveillance systems, automating the integration of expanded monitoring and the transfer of continuous monitoring data to EMRs. Radius VSM has received the CE Mark, and has been released in limited European markets.
Radius PCG. Radius PCG is a portable-real-time capnograph with wireless Bluetooth® connectivity. Radius PCG connects with Root® to provide seamless, tetherless mainstream capnography for patients of all ages. Radius PCG has received the CE Mark and FDA 510(k) clearance.
Rad-97®. Rad-97® is a versatile standalone Pulse CO-Oximeter® that features a 1080p HD color display with user-friendly multi-touch navigation and Masimo SET® Measure-through Motion and Low Perfusion pulse oximetry technology that can be used to measure SpO2, PR, PVi® and Pi rainbow SET® measurements such as SpHb®, SpOC, SpCO®, SpMet® and RRa® can also be enabled. Rad-97® is the smallest Masimo bedside device currently capable of monitoring the full rainbow SET® platform. An optional integrated camera allows remote clinicians to interact with patients at home over live audio and video. With its built-in enterprise Wi-Fi capability, Rad-97® has the ability to connect wirelessly from the home to supplemental patient monitoring systems, including Patient SafetyNet, facilitating automatic data transfer to hospital EMR systems. Rad-97® has received the CE Mark and FDA 510(k) clearance, including an additional Rad-97® configuration with integrated NomoLine® capnography. Rad-97® has also received FDA 501(k) clearance for home use, bringing hospital-grade technology to the home in a single integrated device that is a monitoring, connectivity and telecommunications hub.
Rad-97® NIBP. Rad-97® NIBP includes an integrated port that allows clinicians to connect a blood pressure cuff inflation hose directly to the device. Designed for reliability and patient comfort, Rad-97® NIBP is compatible with both disposable and reusable cuffs for a variety of patient types. Rad-97® NIBP enables clinicians to measure arterial blood pressure for adult, pediatric and neonatal patients, with three measurement modes: spot-check, automatic interval (which measures blood pressure routinely, at a desired interval) and stat interval (which continually measures blood pressure for a desired duration).
Rad-67®. Rad-67®, our handheld Pulse CO-Oximeter®, is a compact, portable spot-check device that offers Masimo SET® Measure-through Motion and Low Perfusion pulse oximetry technology with SpO2, PR and Pi measurements and upgradeable rainbow® noninvasive monitoring technology for SpHb®. With the universal reusable rainbow® DCI®-mini sensor, Rad-67® features Next Generation SpHb® technology. The Rad-67® with next generation SpHb® technology has received the CE Mark and FDA 510(k) clearance.
Rad-57®. Rad-57® is a fully featured handheld Pulse CO-Oximeter® that provides continuous, noninvasive measurement of SpO2, PR, PVi® and Pi with the ability to upgrade to SpHb®, SpCO®, SpMet® and SpOC. Its rugged and lightweight design makes it applicable for use in hospital and field settings, specifically for fire departments and emergency medical service units.
Rad-8®. Rad-8® is a bedside pulse oximeter featuring Masimo SET® Measure-through Motion and Low Perfusion pulse oximetry technology with SpO2, PR and Pi measurement, but without the ability to update to rainbow® technology. Rad-8® is an affordable, low-cost design with a streamlined feature set.
Rad-5® & Rad-5v®. Rad-5® and Rad-5v® were Masimo’s first dedicated lightweight, user-configurable, handheld pulse oximeters to provide Masimo SET® Measure-through Motion and Low Perfusion technology with SpO2, PR and Pi measurements, but without the ability to upgrade to rainbow® technology.
Rad-G. Rad-G is a low-cost, rugged, handheld pulse oximetry device with a rechargeable battery and LCD display. It uses Masimo SET® Measure-through Motion and Low Perfusion pulse oximetry technology to measure SpO2, PR, Pi, PVi® and RRp®. Rad-G was designed primarily for use in pneumonia screening, spot-checking, and continuous measurement of SpO2 and RRp® in low-resource settings. Rad-G has received the CE Mark and FDA 510(k) clearance.
20

Table of Contents

Rad-G with Temperature. The Rad-G with Temperature provides all the important parameters of the Rad-G, but with the added functionality of clinical-grade, real-time forehead non-contact infrared thermometry. The Rad-G with Temperature makes it easier for clinicians to quickly assess patients and make informed care decisions anywhere pulse oximetry or vital signs checking is needed in a compact, portable form factor. Rad-G with Temperature has received the CE Mark, but is not currently available for sale in the U.S.
Pronto®. Pronto® is a handheld noninvasive multiparameter testing device that uses Masimo rainbow SET® technology to provide spot-check measurement of SpO2, PR, Pi and SpHb® in both hospitals (i.e., emergency departments) and remote settings such as physician offices.
SatShare®. Our SatShare® technology enables a conventional monitor to receive continuous measurement updates using Masimo SET® through a simple cable connection from the back of Radical-7® to the sensor input port on the conventional monitor. No software upgrades or new modules are necessary for the upgrade, which can be completed in minutes. SatShare® allows hospitals to standardize the technology and sensors used throughout the hospital while allowing them to gain the more accurate monitoring capabilities using Masimo SET®, as well as other additional functionality, in a cost-effective manner. SatShare® technology has facilitated many hospital-wide conversions of previously installed competitor monitors to Masimo SET®. In addition, Masimo rainbow SET® measurements such as SpHb® are available to clinicians on the Radical-7® itself while the device is being used in SatShare® mode.
MightySat® Rx. MightySat® Rx is a fingertip pulse oximeter that incorporates Masimo SET® Measure-through Motion and Low Perfusion pulse oximetry technology, which measures and displays SpO2, PR and Pi with the option to add PVi® and RRp®. The MightySat® Rx has received the CE Mark and FDA 510(k) clearance. The RRp® measurement on the MightySat® Rx fingertip pulse oximeter has received the CE Mark. MightySat® Rx also received FDA 510(k) clearance of spot-check RRp® measurement.
iSpO2® Rx. The iSpO2® Rx pulse oximeter combines a fingertip sensor, cable and pulse oximeter in a lightweight, portable device that connects directly to a smart device for displaying measurements. iSpO2® Rx uses Masimo SET® Measure-through Motion and Low Perfusion pulse oximetry technology to measure SpO2, PR and Pi. The Masimo Professional Health app, available for both iOS® and Android® devices, allows clinicians to track, trend and download patient data. iSpO2® Rx has received the CE Mark, but is not currently available for sale in the U.S.
SedLine® MOC-9® Module. Our SedLine® MOC-9® module for Root® is an EEG-based continuous brain function monitor that provides information about a patient’s response to anesthesia. Our Next Generation SedLine® enhances PSi to make it less susceptible to EMG interference and to improve performance in low-power EEG cases.
O3® MOC-9® Module. Our O3® MOC-9® module for Root® uses NIRS to detect regional hypoxemia by continuously measuring tissue oxygen saturation (rSO2), automating the differential analysis of regional to central oxygen saturation.
NomoLine® Capnography and Gas Monitoring. Our gas analyzers, IRMA and ISA, are available through Root® MOC-9® modules via OEM integration or through an emergency capnometer (EMMA®). These analyzers enable our customers to benefit from CO2, N2O, O2 and anesthetic agent monitoring in many hospital environments.
TIR-1. Our non-contact clinical-grade infrared thermometer with Bluetooth® connectivity provides forehead temperature measurement across all patient populations. The non-contact module reduces the risk for patient cross-contamination while also reducing costs and waste by eliminating the need for probe covers and other disposables. The Bluetooth® technology automates data transfer to a connected Masimo device, such as Root®, enabling streamlined integration into the bedside device and EMR.
Sensors
Sensors and Cables. We have developed one of the broadest lines of single-patient-use (disposable), reusable and rainbow® sensors and cables. In total, we have over 150 different types of sensors designed to meet virtually every clinical need. Masimo SET® sensors are uniquely designed to reduce interference from physiological and non-physiological noise. Our proprietary technology platforms operate only with our proprietary sensor lines. However, through the use of adapter cables, our sensors can be connected to certain competitor pulse oximetry monitors. We sell our sensors and cables to end-users directly or through our distributors and OEM partners.
Our single-patient-use sensors offer several advantages over reusable sensors, including improved performance, cleanliness, increased comfort and greater reliability. Our reusable sensors are primarily used for short-term, spot-check monitoring.
RD SET®, RD rainbow SET®, and RD rainbow Lite SET®. Our RD family of sensors is designed to maximize patient comfort, optimize clinician workflow and reduce material waste. RD sensors are lightweight with no moving parts and a flat, soft cable with smooth edges. RD sensors are available in fold-over and wrap-around styles for a variety of patient types and clinical scenarios.
21

Table of Contents

SofTouch Sensors. SofTouch sensors are designed with less or no adhesive for patients with compromised skin conditions. SofTouch sensors are available as single-patient sensors for newborns and multi-site reusable sensors for pediatrics and adults.
Trauma and Newborn Sensors. We have developed two specialty sensor lines, for trauma and resuscitation situations, as well as for newborns. These sensors contain an identifier that automatically sets the pulse oximeter to its maximum sensitivity and fastest settings, and allow for quick application, even in wet and slippery environments. Additionally, we introduced low-profile sensors LNCS® and M-LNCS® Neo, NeoPt and Inf sensors to monitor oxygen saturation in newborns. These sensors are smaller and thinner, making them significantly more comfortable for patients and easier for clinicians to apply.
Blue® Sensors. We believe our Blue® Sensors are the first FDA-cleared sensors to accurately monitor arterial blood oxygen saturation levels in cyanotic infants and children with abnormally low oxygen saturation levels.
E1® Ear Sensor. We believe that our E1® Ear Sensor is the first single-patient-use ear sensor that can be placed securely in the ear conchae, allowing clinicians to combine Masimo SET® performance and central monitoring to provide quick access and responsive assessment of oxygenation. The E1® Ear Sensor is designed for field emergency medical services utilization.
TFA-1® Adhesive Forehead Sensor. We designed our TFA-1® forehead sensor for hospitals desiring forehead monitoring using a disposable sensor. TFA-1® combines Masimo SET® performance with quick access and responsive oxygenation assessment.
rainbow® Sensors. We developed these proprietary, multi-wavelength sensors for use with our rainbow® Pulse CO-Oximetry products. In contrast to traditional sensors that only have the capability to monitor SpO2, and PR, our rainbow® sensors can also monitor SpCO®, SpMet® and SpHb®. Our licensed rainbow SET® sensors are the only sensors that are compatible with our licensed rainbow SET® products. Rainbow® sensors are available in single-patient-use, and reusable spot-check sensor types.
The rainbow® DCI®-mini is the first noninvasive hemoglobin spot-check sensor for infants and small children (weight 3 to 30 kg). Paired with our handheld Pronto® or Rad-67® devices, the rainbow® DCI®-mini sensors are designed to help clinicians quickly and easily spot-check hemoglobin levels in infants and small children, which may facilitate the identification of anemia. When paired with Rad-67®, the rainbow® DCI®-mini enables Next Generation SpHb® measurements. The rainbow® DCI®-mini has received the CE Mark in Europe and Ministry of Health, Labour and Welfare (MHLW) approval in Japan, but is not currently available for sale in the U.S. The rainbow® Super DCI®-mini sensor allows for the ability to measure SpHb®, SpCO®, SpMet® and SpO2 on the same noninvasive reusable sensor. The rainbow® Super DCI®-mini has received the CE Mark in Europe and MHLW approval in Japan, but is not currently available for sale in the U.S.
rainbow Acoustic® Sensors. We believe we were the first to market a continuous respiration rate monitoring technology based on an acoustic sensor placed on the patient’s neck. Our rainbow Acoustic® sensors detect the sounds associated with breathing and convert the sounds into continuous respiration rate using proprietary signal processing that is based on Masimo SET®. RAS-45, our single-use acoustic respiration sensor for RAM®, is designed to facilitate placement on and improve attachment to the neck. RAS-45 operates with Masimo MX circuit boards to measure RRa® and display an acoustic respiration wave form. Like the RAS-125c sensor, RAS-45 operates with Masimo MX technology boards to measure RRa®, display the acoustic respiration wave form and optionally allow clinicians to listen to the sound of breathing. Both the RAS-45 and RAS-125c are available in CE Marked countries and the U.S. for adult and pediatric patients who weigh more than 10 kg. RAS-45 has received the CE Mark and FDA 510(k) clearance.
SedLine® Sensor. Used with the SedLine® MOC-9® module for the Root® patient monitoring and connectivity platform, the SedLine® sensor is a disposable sensor that collects EEG data for our SedLine® monitor. RD SedLine sensors feature a repositioned, color-coded sensor-cable connection that lies comfortably on the patient’s head and soft foam pads to reduce discomfort upon application to the patient.
O3® Sensors. Used with the O3® MOC-9® module for the Root® patient monitor, each O3® sensor contains four light-emitting diodes and two detectors to continuously measure rSO2. Our pediatric application of O3® regional oximetry with the O3® pediatric sensor for both adult patients and pediatric patients weighing more than 5 kg (11 lbs) and less than 40 kg (88 lbs) has received FDA 510(k) clearance. O3® sensors for use with infants and neonatal patients has also received FDA 510(k) clearance.
Centroid. Centroid is a wearable wireless patient orientation, activity and respiration rate sensor. Centroid helps clinicians monitor a patient’s position to avoid preventable pressure ulcers and can alert clinicians to sudden movements such as fall-like events. In addition, Centroid detects chest movements to continuously provide respiration rate, providing clinicians with additional data that may inform care decisions. Centroid pairs with the Root® platform using Bluetooth® to track a patient’s posture, orientation and activity. The data transmitted by Centroid can be displayed in various formats on Root®, giving clinicians multiple ways to assess adherence to protocols regarding tissue stress and to tailor care to the specific needs of each patient.
22

Table of Contents

Proprietary Measurements and Features
All of our monitors shipped since January 2006, including Radical-7® and certain future OEM products, that incorporate the MX circuit board will allow purchases of software for rainbow® measurements, as well as other future measurements. Our current rainbow® measurements include SpHb®, SpCO®, SpMet®, SpOC ORi, Pi, PR, PVi®, RPVi, RRp®, SpfO2and RRa®.
Eve. Eve is our newborn screening software application for our Radical-7® Pulse CO-Oximeter®, is designed to help clinicians more effectively and efficiently screen newborns for CCHD. In the Radical-7® Pulse CO-Oximeter®, Eve automates the screening steps with animated instruction, including sensor application, measurement selection and screening result determination. Eve is intended to provide consistent application of the screening protocol to reduce method-and operator-induced variability and improve efficiency by automating the data capture and comparison between readings. Eve has received the CE Mark, but is currently not available for sale in the U.S.
X-Cal®
Sensor and cable failures can prevent pulse oximeters from providing the patient safety advantages that continuous pulse oximetry monitoring is intended to provide. Our X-Cal® technology enhances patient safety and improves clinician efficiency by preserving system quality, performance and reliability and reducing the chances of bad or inferior sensors and cables being used on patients. X-Cal® technology enhances the benefits of Masimo’s pulse oximetry by incorporating the means to track the expected monitoring life of our sensors and cables and provides appropriate user messaging on the host monitor.
X-Cal® addresses three common problems experienced by clinicians using an integrated Masimo system, including:
Patient safety may be compromised by using counterfeit Masimo sensors and cables because they are not produced with comparable components, do not provide proper shielding from ambient interferences, create electrostatic noise caused by motion, do not have our quality and performance controls, and are not tested or warranted to work within a Masimo system;
We design our sensors and cables to last well beyond their warranty period and customer feedback indicates our sensors and cables last significantly longer than competing products, but cable and sensor reliability may still be compromised when used beyond their intended life, affecting patient care and causing clinicians and biomedical engineers to spend time troubleshooting intermittent cable and sensor issues; and
We believe that third-party reprocessed pulse oximetry sensors introduce challenges in the clinical environment due to potential quality issues. In fact, we believe that most third-party reprocessed sensors do not indicate that they are capable of performing in the same conditions as Masimo Measure-through Motion and Low Perfusion sensors or in neonatal applications, key performance requirements available with Masimo SET® sensors. To the best of our knowledge, no third-party company has attempted to reprocess rainbow SET® sensors.
The Masimo Hospital Automation Platform and Iris® Connectivity
Masimo Patient SafetyNet. Patient SafetyNet is a supplemental remote monitoring and clinician notification system that routes bedside-generated alarms through a server to a qualified clinician’s handheld paging device in real-time. Each system can support up to 200 bedside monitors and can either be integrated into a hospital’s existing IT infrastructure or operate as a stand-alone wireless network.
Iris®. Iris® connectivity ports on Root®. allows third-party devices, such as intravenous pumps and ventilators, to connect to Root® enabling display of measurements and notification on the Root® monitor, with the ability to document results in the EMR through Masimo Patient SafetyNet.
Iris® Gateway. Iris® Gateway bridges the gap between device data generated at the patient bedside and documentation in patient data management systems by automatically transferring data from medical devices to EMRs, improving productivity and reducing the likelihood of transcription errors.
Iris® Device Management System (Iris® DMS). Iris® DMS is an automation and connectivity solution designed to streamline management of Masimo devices used throughout a hospital system. Iris® DMS is designed to address the challenges of maintaining many patient monitors in a complex hospital environment. Iris® DMS securely connects over a hospital’s existing network to all connected Masimo devices to provide an easy-to-use dashboard that allows biomedical engineers and IT professionals to view detailed diagnostic information about connected Masimo devices at a glance, without the need to physically interact with each device. Iris® DMS supports remote software upgrades to ensure all devices stay up to date, easily and efficiently.
23

Table of Contents

iSirona. iSironais a compact, versatile connectivity hub designed to maximize interoperability across the continuum of care. The iSirona hub offers an efficient way to physically connect up to six medical devices at the bedside and automatically route the data to the Masimo Hospital Automation platform for EMR integration, surveillance monitoring, alarm management, mobile notifications, smart displays and analytics.
Analytics and Reporting
Trace™. Trace is the first data visualization and reporting software compatible with the full capabilities of the Root® patient monitoring and connectivity platform, including Radical-7® and Radius-7® Pulse CO-Oximeters®, Root® with integrated noninvasive blood pressure and temperature, and connected MOC-9® modules such as SedLine® brain function monitoring, ISA and ISA OR+ capnography, and O3® Regional Oximetry. Trace can create insightful, easy-to-read patient reports that include parameter trends, histograms, event annotations, and key statistics. Trace can communicate with Masimo devices via high-speed wired or wireless connections, with the ability to transfer up to 96 hours of patient data.
Iris® Analytics. Iris® Analytics is a supplemental tool that works in conjunction with the Masimo Hospital Automation platform to generate customizable alarm analytics, individual patient reports, and even hospital-wide reports across the continuum of care.
Halo ION®. Halo ION® is a comprehensive, scalable and customizable continuous early warning score. Halo ION® allows clinicians to aggregate trend data from as few as three physiological parameters (for example, SpO2, PR and PI), and as many as are available, including data from EMRs, into a single continuous early warning score. Each patient’s Halo ION® score is displayed on the Masimo Patient SafetyNet Supplemental Remote Monitoring and Clinician Notification System as a number ranging from zero to 100, helping to streamline clinicians’ patient assessment workflow.
Hospital-to-Home and Wellness
Masimo SafetyNet. Masimo SafetyNet is a home-based patient engagement and remote care automation platform, which provides a complete end-to-end home care solution, allowing clinicians to create and manage treatment plans, patient schedules and patient data flow using automated, customizable CarePrograms, home device data aggregation, and a web-based provider dashboard. CarePrograms are delivered to patients’ smartphones via an app (available for both iOS® and Android® devices) and dynamically update based on patient input, including both self-reported data and physiological data collected by connected monitoring devices. Masimo SafetyNet was developed in the wake of the COVID-19 pandemic to assist with hospital surge capacity and provide clinicians a secure cloud-based platform to remotely manage a patient’s health. Powered by Masimo SET® Measure-through Motion and Low Perfusion technology, the tetherless single-patient-use sensor (Radius PPG) provides continuous respiration rate and oxygen saturation monitoring, with a second tetherless sensor, Radius T°, for continuous temperature measurements. Patient data is sent securely via Bluetooth to the Masimo SafetyNet mobile application.
Masimo SafetyNet Alert. Masimo SafetyNet Alert is an arterial blood oxygen saturation monitoring and alert system designed for use at home. Masimo SafetyNet Alert features Masimo SET® technologies in a wearable fingertip pulse oximetry sensor that communicates wirelessly to an accompanying home medical hub and smartphone app. Masimo SafetyNet Alert monitors blood oxygen saturation (SpO2) and pulse rate (PR) using clinically proven Masimo SET® Measure-through Motion and Low Perfusion™ pulse oximetry and perfusion index (Pi). The system provides escalating alerts when drops in oxygen levels are detected, designed to wake up the person suffering from opioid overdose and if they do not, to send alerts to others when help may be needed. Masimo SafetyNet Alert has received the CE Mark, but is not available for sale in the United States.
Radius T° Continuous Thermometer. The Radius T° Continuous Thermometer is a wearable wireless thermometer that continuously and seamlessly measures temperatures using a small, inconspicuous, wearable sensor that can be easily applied to anyone from children to elderly adults with no action needed after initial application to the skin. Radius T° eliminates manual measurements while providing continuous insight into changes in the user’s temperature and helps users understand which way their temperature is trending. In addition, Radius T° uses proprietary algorithms to provide body temperature measurements, for users five years or older, that approximate oral temperature, not just external skin temperature, with laboratory accuracy within ±0.1°C, whereas other thermometry solutions typically have laboratory accuracy within ±0.2°C. Radius T° has received FDA 510(k) clearance for both prescription and over-the-counter (OTC) use on patients and consumers five years and older.
Masimo Sleep. Masimo Sleep is designed to help consumers better understand the quality of their sleep, Masimo Sleep is fueled by the same expertise in signal processing and sensor development that drives our hospital products used by leading institutions to monitor millions of patients a year.
MightySat®. MightySat® is our fingertip pulse oximeter for personal use that provides SpO2, PR and Pi measurements for health and wellness applications. MightySat®, which is also available with RRp® and PVi®, provides measurements in a compact, battery-powered design with a large color screen that can be rotated for real-time display of the measurements. Bluetooth® wireless functionality enables measurement display via a free, downloadable Masimo Personal Health application on iOS® and Android® mobile devices, as well as the ability to trend and communicate measurements, including the Apple Health Kit.
24

Table of Contents

MightySat® is available through consumer retailers and directly from Masimo, and is intended for general health and wellness use only. MightySat® is not intended for medical use.
iSpO2®. iSpO2® is a personal use pulse oximeter that combines a fingertip sensor, cable and pulse oximeter in a lightweight, portable device that connects directly to a smart device for displaying measurements. iSpO2® uses Measure-through Motion and Low Perfusion SET® technology to measure SpO2, PR and Pi. The Masimo Personal Health app, available for both iOS® and Android® devices, allows users to track, trend and download their data, as well as share it with the Apple Health app. iSpO2® is available through consumer retailers and directly from Masimo and is intended for general health and wellness use only. iSpO2® is not intended for medical use.
Cercacor Laboratories, Inc.
Cercacor is an independent entity spun-off from us to our stockholders in 1998. Joe Kiani, our Chairman and Chief Executive Officer, is also the Chairman and Chief Executive Officer of Cercacor. We are a party to a cross-licensing agreement with Cercacor, which was amended and restated effective January 1, 2007 (the Cross-Licensing Agreement), which governs each party’s rights to certain intellectual property held by the two companies.
The following table outlines our rights under the Cross-Licensing Agreement relating to specific end-user markets and the related technology applications of specific measurements.
End-User Markets
MeasurementsProfessional Caregiver and
Alternate Care Market
Patient and Pharmacist
Vital Signs(1)
Masimo
(owns)
Cercacor
(non-exclusive license)
Non-Vital Signs(2)
Masimo
(exclusive license)
Cercacor
(owns or exclusive license)
______________
(1)Vital signs measurements include, but are not limited to, SpO2, peripheral venous oxygen saturation, mixed venous oxygen saturation, fetal oximetry, sudden infant death syndrome, ECG, blood pressure (noninvasive blood pressure, invasive blood pressure and continuous noninvasive blood pressure), temperature, respiration rate, CO2, pulse rate, cardiac output, EEG, perfusion index, depth of anesthesia, cerebral oximetry, tissue oximetry and/or EMG, and associated features derived from these measurements, such as 3D alarm®, PVi® and other features.
(2)Non-vital signs measurements include the body fluid constituents other than vital signs measurements and include, but are not limited to, carbon monoxide, methemoglobin, blood glucose, hemoglobin and bilirubin.
Our License to Cercacor. We granted Cercacor an exclusive, perpetual and worldwide license, with sublicense rights, to use our Masimo SET® technology, including all improvements, for the monitoring of non-vital signs measurements and to develop and sell devices incorporating Masimo SET® for monitoring non-vital signs measurements in the “Cercacor Market”. The Cercacor Market consists of any product market in which a product is intended to be used by a patient or pharmacist rather than a professional medical caregiver regardless of the particular location of the sale, including sales to doctors, hospitals, alternate care market professionals or otherwise, provided the product is intended to be recommended, or resold, for use by the patient or pharmacist. We also granted Cercacor a non-exclusive, perpetual and worldwide license, with sublicense rights, to use Masimo SET® for the measurement of vital signs in the Cercacor Market. In exchange, Cercacor pays us a 10% royalty on the amount of vital signs sensors and accessories sold by Cercacor.
Cercacor’s License to us. We exclusively license from Cercacor the right to make and distribute products in the “Masimo Market” that utilize rainbow® technology for the measurement of carbon monoxide, methemoglobin, fractional arterial oxygen saturation, and hemoglobin, which includes hematocrit. The Masimo Market consists of any product market where the product is intended to be used by a professional medical caregiver, including hospital caregivers, surgicenter caregivers, paramedic vehicle caregivers, doctors’ offices caregivers, alternate care facility caregivers and vehicles where alternative care services are provided. We also have the option to obtain exclusive licenses to make and distribute products in the Masimo Market that utilize rainbow® technology for the monitoring of other non-vital signs measurements, including blood glucose. We have 180 days after proof of feasibility to exercise the above-referenced option to obtain a license for the measurement of blood glucose for an additional $2.5 million and licenses for other non-vital signs measurements for an additional $0.5 million each. The licenses are exclusive until the later of 20 years from the grant of the applicable license or the expiration of the last patent included in the rainbow® technology related to the applicable measurements. To date, we have developed and commercially released devices that measure carbon monoxide, methemoglobin and hemoglobin using licensed rainbow® technology. We also make and distribute products that monitor respiration rate via rainbow Acoustic Monitoring®, which is a Masimo-developed rainbow® technology and, therefore, is not required to be licensed from Cercacor.
25

Table of Contents

Our license to use rainbow® technology for these measurements in these markets is exclusive on the condition that we continue to pay Cercacor royalties on our products incorporating rainbow® technology, subject to certain minimum aggregate royalty thresholds, and that we use commercially reasonable efforts to develop or market products incorporating the licensed rainbow® technology. The royalty is up to 10% of the rainbow® royalty base, which includes handhelds, tabletop and multiparameter devices. Handheld products incorporating rainbow® technology carry a 10% royalty rate. For other products, only the proportional amount attributable to that portion of our devices used to monitor non-vital signs measurements, rather than to monitor vital signs measurements, and sensors and accessories for measuring only non-vital sign parameters are included in the 10% rainbow® royalty base. For multiparameter devices, the rainbow® royalty base includes the percentage of the revenue based on the number of rainbow®-enabled measurements.
For hospital contracts where we place equipment and enter into a sensor contract, we pay a royalty to Cercacor on the total sensor contract revenue based on the ratio of rainbow®-enabled devices to total devices. Pursuant to the terms of the license, we are subject to certain specific annual minimum aggregate royalty payment obligations of $5.0 million per year.
Change in Control. The Cross-Licensing Agreement provides that, upon a change in control:
if the surviving or acquiring entity ceases to use “Masimo” as a company name and trademark, all rights to the “Masimo” trademark will be assigned to Cercacor;
the option to license technology developed by Cercacor for use in blood glucose monitoring will be deemed automatically exercised and a $2.5 million license fee for this technology will become immediately payable to Cercacor; and
the minimum aggregate annual royalties payable to Cercacor for carbon monoxide, methemoglobin, fractional arterial oxygen saturation, hemoglobin and/or glucose will increase to $15.0 million per year until the exclusivity period of the agreement ends, plus up to $2.0 million for each additional measurement with no maximum ceiling for non-vital sign measurements.
For purposes of the Cross-Licensing Agreement, a change in control includes any of the following with respect to us or Cercacor:
the sale of all or substantially all of either company’s assets to a non-affiliated third-party;
the acquisition by a non-affiliated third-party of 50% or more of the voting power of either company;
Joe Kiani, our Chief Executive Officer and the Chief Executive Officer of Cercacor, resigns or is terminated from his position with either company; or
the merger or consolidation of either company with a non-affiliated third-party.
Ownership of Improvements. Any improvements to Masimo SET® or rainbow® technology made by Cercacor, by us, or jointly by Cercacor with us or with any third-party that relates to non-vital signs monitoring, and any new technology acquired by Cercacor, is and will be owned by Cercacor. Any improvements to the Masimo SET® platform or rainbow® technology made by Cercacor, by us, or jointly by Cercacor with us or with any third-party that relates to vital signs monitoring, and any new technology acquired by us, is and will be owned by us. However, for both non-vital signs and vital signs monitoring, any improvements to the technology, excluding acquired technology, will be assigned to the other party and will be subject to the terms of the licenses granted under the Cross-Licensing Agreement. Any new non-vital signs monitoring technology utilizing Masimo SET® that we develop will be owned by Cercacor and will be subject to the same license and option fees as if it had been developed by Cercacor. Also, we will not be reimbursed by Cercacor for our expenses relating to the development of any such technology.
Other Agreements with Cercacor. We have also entered into various other agreements with Cercacor, including an Administrative Services Agreement, a Consulting Services Agreement and a Sublease Agreement. See Note 3 to our accompanying consolidated financial statements included in Part IV, Item 15(a) of this Annual Report on Form 10-K for additional information on these agreements and other transactions with Cercacor.
Government Regulation
As a global medical technology company, we are subject to significant government regulation, compliance requirements, fees and costs, both in the U.S. and abroad. These regulatory requirements subject our products and our business to numerous risks that are specifically discussed within “Risks Related to Our Regulatory Environment” under Part I, Item 1A“Risk Factors” within this Annual Report on Form 10-K. A summary of certain critical aspects of our regulatory environment is included below.
Product Clearance and Approval Requirements
26

Table of Contents

Many of our products are regulated by numerous government agencies, the most significant of which are the U.S. FDA, the national authorities in the European Union (EU) and the United Kingdom (UK), and MHLW in Japan. In addition, there are government agencies that regulate our products in other countries, whose requirements vary substantially from country to country. These agencies require us to comply with laws that regulate the design, development, clinical trials, testing, manufacture, packaging, labeling, storage, distribution, import, export and promotion of many of our products.
In the U.S., unless an exemption applies, each medical device that we wish to market in the U.S. must, generally, first receive from the FDA either clearance of a 510(k) premarket notification or approval of a premarket application (PMA). In some cases, the device may be authorized by FDA through the de novo classification process. The FDA’s 510(k) clearance process requires us to show that our new medical device is substantially equivalent to a legally marketed “predicate” medical device and usually takes from four to nine months, but it may take longer. The PMA process requires us to demonstrate through valid scientific evidence that there is reasonable assurance of safety and effectiveness of the device for its intended use. The PMA process is much more costly, lengthy and uncertain than the process of obtaining 510(k) clearance. Both 510(k) and PMA submissions are subject to user fees. The FDA determines the appropriate process based on the risk classification of the medical device. There are three classifications, from Class I to Class III. The majority of our current regulated products have been deemed Class II devices, requiring 510(k) clearance, while some have been deemed Class I devices.
Most of our OEM partners are required to obtain clearance or approval of their devices that incorporate Masimo’s technologies, like Masimo SET® technology, Masimo rainbow SET® technology, Masimo Board-in-Cable technology, or are used with Masimo’s sensors. We generally grant our OEM partners a right to cross-reference the 510(k) submission files from our cleared Masimo SET® circuit boards, sensors, cables and notification systems.
In the EU, medical devices are currently subject to the Medical Devices Directive 93/42/EEC (MDD). Under the MDD, a medical device may only be placed on the market within the EU if it conforms to certain “essential requirements”. Key requirements include that a medical device achieves its intended performance and does not compromise the clinical condition or safety of patients or the safety and health of users and others, and bears the CE Mark. A medical device that conforms to such essential requirements can bear a CE Mark, which allows the device to be placed on the market throughout the EU. Each medical device that we wish to market in the EU must conform to these requirements.
Conformity is determined through an assessment procedure, which depends upon the risk classification of the device. For our EU medical devices, conformity assessment generally involves a notified body. Notified bodies are often private entities that are authorized or licensed by government authorities to perform, or otherwise have oversight over, such assessments. Notified bodies may also review a manufacturer’s quality systems. If the conformity assessment is successfully completed, the manufacturer may apply a CE Mark to the product. This allows the general commercializing of a product in the EU. However, the product can also be subject to local registration requirements depending on the country.
On May 26, 2021, the existing MDD was repealed and replaced by the Medical Devices Regulation (EU) 2017/745 (MDR). The MDR is similar to the MDD, though it includes significantly more stringent requirements, notably stronger conformity assessment procedures, greater control over notified bodies and their standards, increased transparency, and more robust device vigilance requirements. The MDR applies to the medical devices we commercialize in the EU after May 26, 2021. However, the MDR is subject to certain transitional periods that enable certain notified body certificates to remain valid beyond 2021. For some of our devices, this could be as late as May 2024.
The UK exited the EU on December 31, 2020 (Brexit). The UK does not intend to implement the MDR into the laws of Great Britain (England, Scotland and Wales). Northern Ireland is an exception where the MDR will continue to apply. Great Britain instead introduced a new, standalone medical devices framework. Currently, this aligns closely to the MDD. Instead of a CE Mark, medical devices marketed in Great Britain must bear a UKCA Mark. However, EU CE Marks will continue to be recognized in Great Britain until June 30, 2023, as will certificates issued by EU-recognized notified bodies. This arrangement is not reciprocated in the EU. Each medical device that we wish to market in the UK must comply with the national laws in the UK, which going forward may differ from the laws in the EU.
Continuing FDA Regulation
Clinical trials involving medical devices are subject to FDA regulation. Among other requirements, clinical trial sponsors must comply with requirements related to informed consent, Institutional Review Board (IRB) approval, monitoring, reporting, record-keeping, labeling and promotion. If the study involves a significant risk device, the sponsor must obtain FDA approval of an investigational device exemption in addition to IRB approval prior to beginning the study. Information regarding certain device clinical trials must also be submitted to a public database maintained by the National Institutes of Health.
After a device is approved and placed on the market, numerous regulatory requirements continue to apply. These regulatory requirements include, but are not limited to, the following: product listing and establishment registration; adherence to the Quality System Regulation (QSR) which requires stringent testing, control, documentation and other quality assurance
27

Table of Contents

procedures for the design, manufacture, storage and handling of devices; labeling requirements and FDA prohibitions against the promotion of off-label uses or indications; adverse event and device malfunction reporting; post-approval restrictions or conditions, including post-approval clinical trials or other required testing; post-market surveillance requirements; the FDA’s recall authority, whereby it can ask for, or require, the recall of products from the market; and requirements relating to voluntary corrections or removals. Device manufacturers are subject to announced and unannounced inspections by the FDA to evaluate compliance with these requirements.
Advertising and Promotion
Advertising and promotion of medical devices, in addition to being regulated by the FDA, are also regulated by the Federal Trade Commission (FTC) and by federal and state regulatory and enforcement authorities, including the Department of Justice, the Office of Inspector General of the Department of Health and Human Services, and various state attorneys general. Although physicians are permitted to use their medical judgment to use medical devices for indications other than those cleared or approved by the FDA, we may not promote our products for such “off-label” uses and can only market our products for cleared or approved uses. Other companies’ promotional activities for their FDA-regulated products have been the subject of FTC enforcement actions brought under healthcare reimbursement laws and consumer protection statutes. FTC enforcement actions often result in consent decrees that constrain future actions. In addition, under the federal Lanham Act and similar state laws, competitors and others can initiate litigation relating to advertising claims.
Import and Export Requirements
To import a device, the importer must file an entry notice and bond with the United States Bureau of Customs and Border Protection (CBP). All devices are subject to FDA examination before release from CBP. Any article that appears to be in violation of the Federal Food, Drug and Cosmetics Act (FDCA) may be refused admission and a notice of detention and hearing may be issued. If the FDA ultimately refuses admission, the CBP may issue a notice for redelivery and, if a company fails to redeliver the goods or otherwise satisfy CBP and the FDA with respect to their disposition, may assess liquidated damages for up to three times the value of the lot. The CBP also imposes its own regulatory requirements on the import of our products, including inspection and possible sanctions for noncompliance.
Products exported from the United States are subject to foreign countries’ import requirements and the exporting requirements of the FDA or European regulating bodies, as applicable. In particular, international sales of medical devices manufactured in the United States that are not approved or cleared by the FDA for use in the United States, or are banned or deviate from lawful performance standards, are subject to FDA export requirements.
Foreign countries often require, among other things, a Certificate of Foreign Government (CFG) for export. To obtain a CFG, the device manufacturer must apply to the FDA. The FDA certifies that the product has been granted clearance or approval in the United States and that the manufacturing facilities were in compliance with the FDA’s QSR regulations at the time of the last FDA inspection.
Conflict Minerals and Supply Chain
We are subject to certain SEC rules adopted pursuant to the Dodd-Frank Wall Street Reform and Consumer Protection Act concerning “conflict minerals” (generally tin, tantalum, tungsten and gold), From January 1, 2021, similar rules are in force in the EU. Certain of these conflict minerals are used in the manufacture of our products. Although the U.S. rules are being challenged in court, in their present form they require us to investigate the source of any conflict minerals necessary to the production or functionality of our products. If any such conflict minerals originated in the Democratic Republic of the Congo or adjoining countries (the DRC region), we must undertake comprehensive due diligence to determine whether such minerals financed or benefited armed groups in the DRC region. Since our supply chain is complex, our ongoing compliance with these rules could affect the pricing, sourcing and availability of conflict minerals used in the manufacture of our products.
We are also subject to disclosure requirements regarding abusive labor practices in portions of our supply chain under the California Transparency in Supply Chains Act.
28

Table of Contents

Environmental
Our manufacturing processes involve the use, generation and disposal of solid wastes, hazardous materials and hazardous wastes, including silicone adhesives, solder and solder paste, sealants, epoxies and various solvents such as methyl ethyl ketone, acetone and isopropyl alcohol. As such, we are subject to stringent federal, state and local laws relating to the protection of the environment, including those governing the use, handling and disposal of hazardous materials and wastes. Products that we sell in Europe are subject to regulation in EU markets under the Restriction of Hazardous Substances Directive (RoHS). RoHS prohibits companies from selling products which contain certain hazardous materials, including lead, mercury, cadmium, chromium, polybrominated biphenyls and polybrominated diphenyl ethers, in EU member states. In addition, the EU’s Regulation-Registration, Evaluation, Authorization, and Restriction of Chemicals Directive also restricts substances of very high concern in products.
Future environmental laws may require us to alter our manufacturing processes, thereby increasing our manufacturing costs. We believe that our products and manufacturing processes at our facilities comply in all material respects with applicable environmental laws and worker health and safety laws; however, the risk of environmental liabilities cannot be completely eliminated.
Health Care Fraud and Abuse
In the U.S., there are federal and state anti-kickback laws that generally prohibit the payment or receipt of kickbacks, bribes or other remuneration in exchange for the referral of patients or other health-related business. For example, the Federal Anti-Kickback Statute (42 U.S.C. § 1320a-7b(b)) prohibits anyone from, among other things, knowingly and willfully offering, paying, soliciting or receiving any bribe, kickback or other remuneration intended to induce the referral of patients for, or the purchase, order or recommendation of, health care products and services reimbursed by a federal health care program, including Medicare and Medicaid. Recognizing that the federal anti-kickback law is broad and potentially applicable to many commonplace arrangements, Congress and the Office of Inspector General (OIG) within the Department of Health and Human Services have created statutory “exceptions” and regulatory “safe harbors”. Exceptions and safe harbors exist for a number of arrangements relevant to our business, including, among other things, payments to bona fide employees, certain discount and rebate arrangements, and certain payment arrangements involving Group Purchasing Organizations (GPOs).
Although an arrangement that fits into one or more of these exceptions or safe harbors is immune from prosecution, arrangements that do not fit squarely within an exception or safe harbor do not necessarily violate the law, but the OIG or other government enforcement authorities may examine the practice to determine whether it involves the sorts of abuses that the statute was designed to combat. Violations of this federal law can result in significant penalties, including imprisonment, monetary fines and assessments, and exclusion from Medicare, Medicaid and other federal health care programs. Exclusion of a manufacturer, like us, would preclude any federal health care program from paying for its products. In addition to the federal anti-kickback law, many states have their own laws that are analogous to the federal anti-kickback law, but may apply regardless of whether any federal or state health care program business is involved. Federal and state anti-kickback laws may affect our sales, marketing and promotional activities, educational programs, pricing and discount practices and policies, and relationships with health care providers by limiting the kinds of arrangements we may have with hospitals, alternate care market providers, GPOs, physicians, payers and others in a position to purchase or recommend our products.
Federal and state false claims laws prohibit anyone from presenting, or causing to be presented, claims for payment to third-party payers that are false or fraudulent. For example, the Federal Civil False Claims Act (31 U.S.C. § 3729 et seq.) imposes liability on any person or entity who, among other things, knowingly and willfully presents, or causes to be presented, a false or fraudulent claim for payment by a federal health care program, including Medicaid and Medicare. Some suits filed under the False Claims Act, known as “qui tam” actions, can be brought by a “whistleblower” or “relator” on behalf of the government and such individuals may share in any amounts paid by the entity to the government in fines or settlement. Manufacturers, like us, can be held liable under false claims laws, even if they do not submit claims to the government, where they are found to have caused submission of false claims by, among other things, providing incorrect coding or billing advice about their products to customers that file claims, or by engaging in kickback arrangements or off-label promotion with customers that file claims. A number of states also have false claims laws, and some of these laws may apply to claims for items or services reimbursed under Medicaid and/or commercial insurance. Sanctions under these federal and state fraud and abuse laws may include civil monetary penalties and criminal fines, exclusion from government health care programs and imprisonment.
The Health Insurance Portability and Accountability Act of 1996 (HIPAA) created new federal crimes, including health care fraud and false statements related to health care matters. The health care fraud statute prohibits, among other things, knowingly and willfully executing a scheme to defraud any health care benefit program, including those offered by private payers. The false statements statute prohibits, among other things, knowingly and willfully falsifying, concealing or covering up a material fact or making any materially false, fictitious or fraudulent statement in connection with the delivery of or payment for health care benefits, items or services. A violation of either statute is a felony and may result in fines, imprisonment and other significant penalties.
29

Table of Contents

The Physician Payment Sunshine Act (Sunshine Act), which was enacted by Congress as part of the ACA, requires medical device companies to track and publicly report, with limited exceptions, all payments and transfers of value to physicians and teaching hospitals in the U.S. Companies are required to track payments made and to report such payments to the government by March 31 of each year. Several states have similar requirements. Beginning in 2022, the reporting requirement also applies to advance practice nurses and physician assistants.
The Foreign Corrupt Practices Act of 1977 and similar worldwide anti-bribery laws in non-U.S. jurisdictions generally prohibit companies and their intermediaries from making improper payments to non-U.S. officials for the purpose of obtaining or retaining business.
Due to the breadth of some of these laws, it is possible that some of our current or future practices might be challenged under one or more of these laws. In addition, there can be no assurance that we would not be required to alter one or more of our practices to be in compliance with these laws. Evolving interpretations of current laws or the adoption of new federal or state laws or regulations could adversely affect many of the arrangements we have with customers and physicians. Therefore, our risk of being found in violation of these laws is increased by the fact that some of these laws are broad and open to interpretation.
Data Privacy and Protection of Health and Other Personal Information
Data protection legislation is becoming increasingly common in the United States at both the federal and state level. For example, the California Consumer Privacy Act of 2018 (CCPA), which became effective on January 1, 2020, requires us to make disclosures to consumers about our data collection, use and sharing practices, allows consumers to opt out of certain data sharing with third parties, and provides a cause of action for data breaches. The CCPA, together with the Consumer Privacy Rights Act, which will be effective beginning January 1, 2023, is the most comprehensive data privacy law in the United States, and could be the precursor to other similar legislation in other states or at the federal level. Internationally, the General Data Protection Regulation (GDPR) took effect in May 2018 within the European Economic Area (EEA) and many EEA jurisdictions. Other jurisdictions outside of the EEA have also adopted their own data privacy and protection laws. We have implemented, and continue to implement, procedures and processes to comply with these regulations and, as international data privacy and protection laws continue to evolve, and as new regulations, interpretive guidance and enforcement information become available, we may incur incremental costs to modify our business practices to comply with these requirements. In addition, our internal control policies and procedures may not always protect us from reckless or criminal acts committed by our employees or agents.
In addition, numerous federal, state and international laws and regulations, including HIPAA and GDPR, govern the collection, use and disclosure of patient-identifiable, protected health information (PHI) and other personal information. In the U.S., HIPAA applies to covered entities, which include most healthcare facilities that purchase and use our products, and their business associates. The HIPAA Privacy Rule restricts the use and disclosure of PHI, and requires covered entities and their business associates to safeguard that information and to provide certain rights to individuals with respect to that information. The HIPAA Security Rule establishes detailed requirements for safeguarding PHI transmitted or stored electronically.
Although we are not a covered entity, we are sometimes deemed by our customers to be a business associate of covered entities due to activities that we perform for or on behalf of covered entities, such as training customers on the use of our products or investigating product performance. As business associates, we are subject to many of the requirements of HIPAA and could be directly subject to HIPAA civil and criminal enforcement and the associated penalties for violation of the Privacy, Security and Breach Notification Rules.
The HIPAA standards also apply to the use and disclosure of PHI for research and generally require the covered entity performing the research to obtain the written authorization of the research subject (or an appropriate waiver) before providing that subject’s PHI to sponsors like us for purposes related to the research. These covered entities also typically impose contractual limitations on our use and disclosure of the PHI they disclose to us. We may be required to make costly system modifications to comply with the privacy and security requirements that will be imposed on us and our failure to comply may result in liability and adversely affect our business. Other countries also have, or are developing, laws governing the collection, use and transmission of health information, and these laws could create liability for us or increase our cost of doing business.
Third-Party Reimbursement
Health care providers, including hospitals, that purchase our products generally rely on third-party payers, including the Medicare and Medicaid programs and private payers, including indemnity insurers and managed care plans, to cover and reimburse all or part of the cost of the products and the procedures in which they are used. As a result, demand for our products is dependent in part on the coverage and reimbursement policies of these payers. No uniform coverage or reimbursement policy for medical technology exists among all third-party payers, and coverage and reimbursement can differ significantly from payer to payer.
30

Table of Contents

The Centers for Medicare & Medicaid Services (CMS) is the federal agency responsible for administering the Medicare program. Along with its contractors, CMS establishes the coverage and reimbursement policies for the Medicare program. Because a large percentage of our products are used in the treatment of elderly or disabled individuals who are Medicare beneficiaries, Medicare’s coverage and reimbursement policies are particularly significant to our business. In addition, private payers often follow the coverage and reimbursement policies of Medicare.
In general, Medicare will cover a medical product or procedure when the product or procedure is included within a statutory benefit category and is reasonable and necessary for the diagnosis or treatment of an illness or injury, or to improve the functioning of a malformed body part. Even if the medical product or procedure is considered medically necessary and coverage is available, Medicare may place restrictions on the circumstances where it provides coverage. For example, several Medicare local contractors have issued policies that restrict coverage for pulse oximetry in hospital inpatient and outpatient settings to a limited number of conditions, including limiting coverage to patients who (i) exhibit signs of acute respiratory dysfunction, (ii) have chronic lung disease, severe cardiopulmonary disease or neuromuscular disease involving the muscles of respiration, (iii) are under treatment with a medication with known pulmonary toxicity, or (iv) have sustained multiple trauma or complaints of acute chest pain.
Reimbursement for our products may vary not only by the type of payer involved but also based upon the setting in which the product is furnished and utilized. For example, Medicare payment may be made, in appropriate cases, for patient stays in the hospital inpatient and in outpatient settings involving the use of our products. Medicare generally reimburses hospitals based upon prospectively determined amounts. For hospital inpatient stays, the prospective payment generally is determined by the patient’s condition and other patient data and procedures performed during the inpatient stay, using a classification system known as Medicare Severity Diagnosis-Related Groups (MS-DRGs). Prospective rates are adjusted for, among other things, regional differences, co-morbidity and complications. Hospitals generally do not receive separate Medicare reimbursement for the specific costs of purchasing our products for use in the inpatient setting. Rather, Medicare reimbursement for these costs is deemed to be included within the prospective payments made to hospitals for the inpatient services in which the products are utilized.
In contrast, some differences may be seen in the reimbursement for use of our products in hospital outpatient departments. In this setting, Medicare payments also are generally made under a prospective payment system based on the ambulatory payment classifications (APCs) under which individual items and procedures are categorized. Hospitals receive the applicable APC payment rate for the procedure regardless of the actual cost for such treatment. Some outpatient services such as oximetry services do not receive separate reimbursement. Rather, their reimbursement is deemed packaged into the APC for an associated procedure and the payment for that APC does not vary whether or not the packaged procedure is performed. Some procedures also are paid through composite APCs, which are APCs that establish a payment rate that applies when a specific combination of services is provided.
Reimbursement for certain pulse oximetry monitoring services, including those using our products, may be separately payable when they are the only service provided to the patient on that day, packaged if provided with certain critical care services, or reimbursed through a composite APC when provided in connection with certain other services.
Because payments through the Prospective Payment System in both the hospital inpatient and outpatient settings are based on predetermined rates and may be less than a hospital’s actual costs in furnishing care, hospitals have incentives to lower their operating costs by utilizing products that will reduce the length of inpatient stays, decrease labor or otherwise lower their costs. If hospitals cannot obtain adequate coverage and reimbursement for our products, or the procedures in which they are used, we cannot be certain that they will purchase our products, despite the clinical benefits and opportunity for cost savings that we believe can be derived from their use.
Our success with rainbow SET® technologies in U.S. settings of care with reimbursable monitoring procedures, such as hospital emergency departments, hospital procedure labs, and physician offices may largely depend on the ability of providers to receive reimbursement for such procedures. While private insurance payers often follow Medicare coverage and payment, we cannot be certain of this and, in many cases, cannot control the coverage or payment rates that private insurance payers put in place. In addition, the potential amendment, repeal or judicial invalidation of the ACA, and/or the enactment of other legislation or regulations, could affect future payment for services involving the use of our products.
Our success in non-U.S. markets depends largely upon the availability of coverage and reimbursement from the third-party payers through which health care providers are paid in those markets. Health care payment systems in non-U.S. markets vary significantly by country, and include single-payer government managed systems, as well as systems in which private payers and government managed systems exist side-by-side. Our ability to achieve market acceptance or significant sales volume in international markets we enter will be dependent in large part on the availability of reimbursement for procedures performed using our products under health care payment systems in such markets.
31

Table of Contents

Other U.S. and Foreign Regulation
We and our OEM partners also must comply with numerous federal, state and local laws, as well as laws in other jurisdictions, relating to matters such as safe working conditions, manufacturing practices, environmental protection, fire hazard control and hazardous substance disposal. We cannot be sure that we will not be required to incur significant costs to comply with these laws and regulations in the future or that these laws or regulations will not hurt our business, financial condition and results of operations. Unanticipated changes in existing regulatory requirements or adoption of new requirements could hurt our business, financial condition and results of operations.
Markets
Competitive Conditions
The medical device industry is highly competitive and many of our competitors have substantially greater financial, technical, marketing and other resources than we do. While we regard any company that sells pulse oximeters as a potential customer, we also recognize that the companies selling pulse oximeters on an OEM basis and/or pulse oximetry sensors are also potential competitors. Our primary competitor, Medtronic plc (Medtronic, formerly Covidien Ltd.), currently holds a substantial share of the pulse oximetry market. In addition, large technology companies that have not historically operated in the healthcare or medical device space, such as Alphabet Inc., Amazon.com, Inc., Apple Inc., Samsung Electronics Co., Ltd. and others, have developed or may develop products and technologies that may compete with our current or future products and technologies in the consumer and clinical marketplaces.
Medtronic sells its own brand of Nellcor pulse oximeters to end-users, sells pulse oximetry modules to other monitoring companies on an OEM basis, and licenses to certain OEMs the right to make their pulse oximetry platforms compatible with their sensors. We also face substantial competition from larger medical device companies, including companies that develop products that compete with our proprietary Masimo SET® and our OEM partners. We believe that a number of companies have announced products that claim to offer motion-tolerant accuracy. In addition, some of our patents have expired and others will expire over time in accordance with the laws of the jurisdiction in which they were issued.
We believe that the principal competitive factors in the market for pulse oximetry products include:
accurate monitoring during both patient motion and low perfusion;
ability to introduce other clinically beneficial measurements related to oxygenation and respiration, such as noninvasive and continuous oxygen reserve index and hemoglobin;
competitive pricing;
brand recognition and perception of innovation abilities;
sales and marketing capability;
access to hospitals which are members of GPOs;
access to integrated delivery networks;
access to OEM partners; and
patent protection.
Market Demand
We currently sell all of our medical products both directly to hospitals and the alternate care market via our sales force and various distributors in the U.S. and around the world, including Europe, the Middle East, Asia, Latin America, Canada and Australia. We sell our non-medical/consumer products through e-commerce Internet sites such as www.masimopersonalhealth.com and www.amazon.com.
Our sales and marketing strategy for pulse oximetry has been, and will continue to be, focused on building end-user awareness of the clinical and cost-saving benefits of our technologies. Our sales representatives’ primary focus is to facilitate the conversion of competitor accounts to our Masimo SET® pulse oximetry and rainbow SET® Pulse CO-Oximetry® products, to expand the use of Masimo SET® and Patient SafetyNet on the general floor and to create and expand the use of rainbow® measurements in both critical care and non-critical care areas. In addition to sales representatives, we employ clinical specialists to work with our sales representatives to educate end-users on the benefits of Masimo SET® and assist with the introduction and implementation of our technology and products to their sites.
For the year ended January 1, 2022, two just-in-time distributors, Medline Industries and Cardinal Health, represented approximately 14.6% and 10.2%, respectively, of our total revenue. These were the only two customers that represented 10% or more of our revenue for the year ended January 2, 2021. Importantly, these two distributors take and fulfill orders from our
32

Table of Contents

direct customers, many of which have signed long-term sensor purchase agreements with us. If a specific just-in-time distributor is unable to fulfill these orders, the orders would be redirected to other distributors or fulfilled directly by us.
Additionally, we sell certain of our products through our OEM partners who incorporate our technologies into their monitors and sometimes resell our sensors to their installed base. Our OEM agreements allow us to expand the availability of our technologies through the sales and distribution channels of each OEM partner. To facilitate clinician awareness of Masimo technologies, our OEM partners have generally agreed to place the applicable Masimo trademark prominently on their instruments.
In order to facilitate our U.S. direct sales to hospitals, we have signed contracts with what we believe to be the five largest national GPOs in the U.S., based on the total volume of negotiated purchases. In return for the GPOs putting our products on contract, we have agreed to pay the GPOs a percentage of our revenue from their member hospitals. In 2021 and 2020, revenue from the sale of our pulse oximetry products to hospitals that are associated with GPOs amounted to $643.1 million and $564.0 million, respectively.
Resources
Intellectual Property
We believe that in order to maintain a competitive advantage in the marketplace, we must develop and maintain protection of the proprietary aspects of our technology. We rely on a combination of patent, trademark, trade secret, copyright and other intellectual property rights and measures to protect our intellectual property.
We have developed a patent portfolio internally, and, to a lesser extent, through acquisitions and licensing, that covers many aspects of our product offerings. As of January 1, 2022, we had approximately 800 issued patents and approximately 500 pending applications in the U.S., Europe, Japan, Australia, Canada and other countries throughout the world. Our patents expire in accordance with the laws of the particular jurisdiction in which they were issued, which sometimes change. Additionally, as of January 1, 2022, we owned approximately 100 U.S. registered trademarks and approximately 500 foreign registered trademarks, as well as trade names that we use in conjunction with the sale of our products. Our trademarks are perpetually renewable.
Under the Cross-Licensing Agreement, we and Cercacor have agreed to allocate proprietary ownership of technology developed based on the functionality of the technology. We will have proprietary ownership, including ownership of all patents, copyrights and trade secrets, of all technology related to the noninvasive monitoring of vital signs measurements, and Cercacor will have proprietary ownership of all technology related to the noninvasive monitoring of non-vital signs measurements. We also rely upon trade secrets, continuing technological innovations and licensing opportunities to develop and maintain our competitive position.
We seek to protect our trade secrets and proprietary know-how, in part, with confidentiality agreements with consultants, vendors and employees, although we cannot be certain that the agreements will not be breached or that we will have adequate remedies for any breach.
There are risks related to our intellectual property rights. For further detail on these risks, see “Risks Related to Our Intellectual Property” under Item 1A“Risk Factors” in this Annual Report on Form 10-K.
Research and Product Development
We believe that ongoing research and development efforts are essential to our success. Our research and development efforts focus primarily on continuing to enhance our technical expertise in pulse oximetry, expanding our noninvasive monitoring of other measurements and developing remote alarm and monitoring solutions.
Although we and Cercacor each have separate research and development projects, we collaborate with Cercacor on multiple research and development activities related to rainbow® technology and other technologies. Under the Cross-Licensing Agreement, the parties have agreed to allocate proprietary ownership of technology developed by either party based on the functionality of the technology. We will have proprietary rights to all technology related to the noninvasive measurement of vital signs measurements, and Cercacor will have proprietary ownership of all technology related to the noninvasive monitoring of non-vital signs measurements.
Manufacturing
Our strategy is to manufacture products in-house when it is efficient and cost-effective for us to do so. We currently manufacture our bedside and handheld pulse oximeters, our full line of disposable and reusable sensors and most of our patient cables in-house or through captive contract maquiladora operations. We maintain an approximate 70,700 square foot manufacturing facility in Irvine, California, and two separate manufacturing facilities in Mexicali and San Luis Rio Colorado,
33

Table of Contents

Mexico that have combined square footage of approximately 333,400 square feet. All three of these facilities are International Organization for Standardization (ISO) 13485:2016 certified. We also maintain an approximate 86,500 square foot facility in Hudson, New Hampshire, a portion of which is used to manufacture advanced light emitting diodes and other advanced component-level technologies.
We will continue to utilize third-party contract manufacturers for products and subassemblies that can be more efficiently manufactured by these parties, such as our circuit boards. We monitor our third-party manufacturers and perform inspections and product tests at various steps in the manufacturing cycle to ensure compliance with our specifications. We also do full functional testing of our circuit boards.
For raw materials, we and our contract manufacturers rely on sole source suppliers for some components, including digital signal processor chips and analog-to-digital converter chips. We and our contract manufacturers have taken steps to minimize the impact of a shortage or stoppage of shipments of digital signal processor chips or analog to digital converter chips, including maintaining a safety stock of inventory and designing software that may be easily ported to another digital signal processor chip. We have agreements with certain major suppliers and each agreement provides for varying terms with respect to contract expiration, termination and pricing. Most of these agreements allow for termination upon specified notice, ranging from four to twelve months, to the non-terminating party. Certain of these agreements with our major suppliers allow for pricing adjustments, each agreement provides for annual pricing negotiation, and one agreement also guarantees us the most favorable pricing offered by the supplier to any of its other customers.
Sustainability
As a global manufacturer of patient monitoring technology, our mission is to improve patient outcomes and reduce the cost of care. We understand the materials we use and the products we manufacture can have an impact on the environment. We are continuously evaluating ways to reduce our overall environmental footprint. We have implemented measures to promote greater environmental responsibility, conserve resources and reduce waste in an effort to help combat climate change.
We are committed to operating in an environmentally responsible manner and support the internationally recognized environmental principles set forth in the United Nations Global Compact. We strive to identify new opportunities to improve the sustainability of our business and encourage our employees to join in our efforts. In furtherance of these commitments, we reinforce the following sustainability principles:
Environmental. We undertake initiatives to promote greater environmental responsibility and incorporate energy efficiency measures in all areas of our business. We comply with applicable environmental protection laws in all areas of our business.
Social. We train and encourage our employees to conduct their activities in an environmentally responsible and sustainable manner.
Economic. We continuously take steps to minimize material waste and energy inefficiencies in our products and manufacturing processes.
Human Capital Resources
Core to our long-term strategy for human capital is attracting, developing and retaining the best talent globally with the right skills to drive our future success. We consider our employees to be our greatest assets and the greatest strength behind our innovation and success. We seek to attract and retain highly-talented, experienced and well-educated individuals to support our long-term growth and profitability goals.
Our success and future growth is largely dependent on our ability to retract, retain and develop a diverse workforce at all levels of the organization. To succeed, we have developed key recruitment and retention strategies that we focus on as part of our overall management of our business. These include:
Compensation. Our compensation programs are designed to align the compensation of our employees with their performance and to provide the proper incentives to attract and retain employees while motivating them to achieve superior results. The structure of our compensation programs balance incentive earnings for both short-term and long-term performance.
Our executive compensation is aligned with stockholder interests by aligning pay-for-performance metrics.
We utilize nationally-recognized compensation consultants to evaluate our executive compensation benefit programs and provide benchmarking against our peer groups.
We provide employee wages that are competitive and consistent with employee positions, experience, skills, knowledge and geography.
Our annual increases and cash incentives are based on market and awarded based on merit.
34

Table of Contents

We offer a wide variety of benefits, including health insurance, paid time off, retirement plans, and voluntary benefits such as financial and personal wellness benefits, etc.
Health and Safety. We are committed to the safety and well-being of our employees. In response to the COVID-19 pandemic, we implemented changes to our business in an effort to protect our employees and customers. We instituted safety protocols and procedures for our essential employees who continue to work on site, including: daily temperature checks upon entering all facilities, implementation of Masimo SafetyNet-Open to pre-clear employees entering our main campus facilities, installation of plexiglass partitions between work stations at our primary manufacturing and assembly facilities, increased distancing and implementation of extensive cleaning and sanitation procedures for our manufacturing and assembly facilities as well as and our general administration and sales facilities.
Developing Leaders of Tomorrow/Succession Planning. We are committed to identifying and developing the talents of our next generation of leaders. Our executive management team conducts organization and leadership reviews of all business leaders, focusing on our high-performing and high potential talent, diversity, and the succession planning for critical roles.
Employee Feedback and Retention. In 2020 and 2021, we were certified as a Great Place to Work®. In addition, for 2021, we were recognized on Fortune Best Workplaces in Manufacturing & Production. To assess and improve employee retention and engagement, we survey employees and take actions to address areas of employee concerns. The average tenure of our employee is approximately 5.1 years and more than 17% of our employees have been employed by us for more than ten years.
Inclusion and Diversity. In fiscal 2021, our full-time employees increased from approximately 2,000 as of January 2, 2021 to 2,200 as of January 1, 2022 and our dedicated contract personnel worldwide decreased from approximately 4,200 as of January 2, 2021 to approximately 4,000 as of January 1, 2022. Of our full-time employees, approximately 66% were male and approximately 34% were female, and women represented approximately 27% of our management/leadership roles. Minorities represented approximately 48% of our U.S. workforce, and approximately 40% of our management/leadership roles.
Available Information
Our annual reports on Form 10-K, quarterly reports on Form 10-Q, proxy statements, current reports on Form 8-K and amendments to those reports filed or furnished pursuant to Section 13(a) or 15(d) of the Securities Exchange Act of 1934, as amended, are available free of charge at our website, www.masimo.com, as soon as reasonably practicable after electronically filing such reports with the SEC. Any information contained on, or that can be accessed through, our website is not incorporated by reference into, nor is it in any way a part of, this Annual Report on Form 10-K.
35

Table of Contents

ITEM 1A.     RISK FACTORS
The following risk factors and other information included in this Annual Report on Form 10-K should be carefully considered. The risks and uncertainties described below are not the only ones we face. Additional risks and uncertainties not presently known to us or that we presently deem less significant may also impair our business operations. If any of the following risks come to fruition, our business, financial condition, results of operations and future growth prospects would likely be materially and adversely affected. In these circumstances, the market price of our common stock could decline, and you could lose all or part of your investment.
Summary of Material Risk Factors
Below is a summary of the principal factors that make an investment in our securities speculative or risky. This summary does not address all of the risks that we face. Additional discussion of the risks summarized in this summary, and other risks that we face, can be found following this summary and should be carefully considered together with all of the other information appearing in this Annual Report on Form 10-K.
We currently derive the majority of our revenue from our Masimo SET® platform, Masimo rainbow SET® platform and related products. If these technologies and related products do not continue to achieve market acceptance, our business, financial condition and results of operations would be adversely affected.
Some of our products are in development or have been recently introduced into the market and may not achieve market acceptance, which could limit our growth and adversely affect our business, financial condition and results of operations.
Our ability to commercialize new products, new or improved technologies and additional applications for Masimo SET® and our licensed rainbow® technology is limited to certain markets by our Cross-Licensing Agreement with Cercacor Laboratories, Inc. (Cercacor), which may impair our growth and adversely affect our business, financial condition and results of operations.
We face competition from other companies, many of which have substantially greater resources than we do. If we do not successfully develop and commercialize enhanced or new products that remain competitive with products or alternative technologies developed by others, we could lose revenue opportunities and customers, and our ability to grow our business would be impaired, adversely affecting our financial condition and results of operations.
We depend on our domestic and international OEM partners for a portion of our revenue. If they do not devote sufficient resources to the promotion of products that use our technologies, our business would be harmed.
If we fail to maintain or develop relationships with GPOs, sales of our products would decline.
Inadequate levels of coverage or reimbursement from governmental or other third-party payers for our products, or for procedures using our products, may cause our revenue to decline or prevent us from realizing revenues from future products.
Consolidation in the healthcare industry could lead to demands for price concessions or to the exclusion of existing market participants from certain markets, which could have an adverse effect on our business, results of operations or financial condition.
Our customers may reduce, delay or cancel purchases due to a variety of factors, such as lower hospital census levels or third-party guidelines, which could adversely affect our business, financial condition and results of operations.
The loss of any large customer or distributor, or any cancellation or delay of a significant purchase by a large customer, could reduce our net sales and harm our operating results.
Counterfeit Masimo sensors and third-party reprocessed single-patient-use Masimo sensors may harm our reputation. Also, these counterfeit and third-party reprocessed sensors, as well as genuine Masimo reprocessed sensors, are sold at lower prices than new Masimo sensors and could cause our revenue to decline, which may adversely affect our business, financial condition and results of operations.
If the patents we own or license, or our other intellectual property rights, do not adequately protect our technologies, we may lose market share to our competitors and be unable to operate our business profitably.
If third parties claim that we infringe their intellectual property rights, we may incur liabilities and costs and may have to redesign or discontinue selling certain products.
We believe competitors may currently be violating and may in the future violate our intellectual property rights. As a result, we may initiate litigation to protect and enforce our intellectual property rights, which may result in substantial expense and may divert management’s attention from implementing our business strategy.
The laws of foreign countries may not adequately protect our intellectual property rights.
Our failure to obtain and maintain FDA clearances or approvals on a timely basis, or at all, would prevent us from commercializing our current, upgraded or new products in the U.S., which could severely harm our business.
36

Table of Contents

The failure of our OEM partners to obtain required FDA clearances or approvals for products that incorporate our technologies could have a negative impact on our revenue.
If we or our suppliers fail to comply with ongoing regulatory requirements, or if we experience unanticipated problems with our products, these products could be subject to restrictions or withdrawal from the market.
Failure to obtain regulatory authorizations in foreign jurisdictions may prevent us from marketing our products abroad.
Modifications to our marketed devices may require new regulatory clearances or premarket approvals, or may require us to cease marketing or to recall the modified devices until clearances or approvals are obtained.
Regulatory reforms may impact our ability to develop and commercialize our products and technologies.
If our products cause or contribute to a death or serious injury, or malfunction in a way that would likely cause or contribute to a death or serious injury, we will be subject to medical device reporting regulations, and may need to initiate voluntary corrective actions or in certain circumstances be required to take corrective actions, such as the recall of our products.
Promotion of our products using claims that are off-label, unsubstantiated, false or misleading could subject us to substantial penalties.
The regulatory environment governing information, cybersecurity and privacy is increasingly demanding and continues to evolve.
We may be subject to or otherwise affected by federal and state healthcare laws, including fraud and abuse laws, and could face substantial penalties if we are unable to fully comply with these laws.
Legislative and regulatory changes in the healthcare industry could have a negative impact on our financial performance. Furthermore, our business, financial condition, results of operations and cash flows could be significantly and adversely affected by healthcare reform legislation in the U.S. or in our key international markets.
Our business, financial condition and results of operations may be adversely affected by the COVID-19 pandemic.
If our employees become ill or otherwise incapacitated, our operations may be adversely impacted.
We may experience conflicts of interest with Cercacor with respect to business opportunities and other matters.
We will be required to assign to Cercacor and pay Cercacor for the right to use certain products and technologies we develop that relate to the monitoring of non-vital sign parameters, including improvements to Masimo SET®.
In the event that the Cross-Licensing Agreement is terminated for any reason, or Cercacor grants a license to rainbow® technology to a third-party, our business would be adversely affected.
We may not be able to commercialize our products incorporating licensed rainbow® technology cost-effectively or successfully.
Rights provided to Cercacor in the Cross-Licensing Agreement may impede a change in control of our company.
If we are unable to obtain key materials and components from sole or limited source suppliers, we will not be able to deliver our products to customers.
Future strategic initiatives, including acquisitions of businesses and strategic investments, could negatively affect our business, financial condition and results of operations if we fail to integrate the acquired businesses successfully into our existing operations or achieve the desired results of our investment.
Our new products and changes to existing products as a result of our proposed acquisition of Sound United could fail to attract or retain users or generate revenue and profits. Further, we may not be successful in our personal consumer strategy and investments, which could adversely affect our business, reputation or financial results.
Our credit agreement contains certain covenants and restrictions that may limit our flexibility in operating our business.
Our proposed new debt facility, which will be used to partially fund our pending acquisition of Sound United, may restrict our future operations, including our ability to respond to changes or to take certain actions. If we fail to comply with the covenants and other obligations under the proposed credit facility, the lender may be able to accelerate amounts owed under the facility.
Concentration of ownership of our stock among our existing directors, executive officers and principal stockholders may prevent new investors from influencing significant corporate decisions.
Our corporate documents and Delaware law contain provisions that could discourage, delay or prevent a change in control of our company, prevent attempts to replace or remove current management and reduce the market price of our stock.
Our bylaws provide that the state or federal courts located within the State of Delaware are the exclusive forum for substantially all disputes between us and our stockholders, which could limit our stockholders’ ability to obtain a favorable judicial forum for disputes with us or our directors, officers or employees.
37

Table of Contents

Risks Related to Our Revenues
We currently derive the majority of our revenue from our Masimo SET® platform, Masimo rainbow SET® platform and related products. If these technologies and related products do not continue to achieve market acceptance, our business, financial condition and results of operations would be adversely affected.
We are highly dependent upon the continued success and market acceptance of our proprietary Masimo SET® and Masimo rainbow SET® technologies that serve as the basis of our primary product offerings. Continued market acceptance of products incorporating these technologies will depend upon us continuing to provide evidence to the medical community that our products are cost-effective and offer significantly improved performance compared to conventional pulse oximeters. Healthcare providers that currently have significant investments in competitive pulse oximetry products may be reluctant to purchase our products. If hospitals and other healthcare providers do not believe our Masimo SET® and Masimo rainbow SET® platforms are cost-effective, safe or more accurate or reliable than competitive pulse oximetry products, they may not buy our products in sufficient quantities to enable us to generate revenue growth from the sale of these products. In addition, allegations regarding the safety and effectiveness of our products, whether or not substantiated, may impair or impede the acceptance of our products.
Some of our products are in development or have been recently introduced into the market and may not achieve market acceptance, which could limit our growth and adversely affect our business, financial condition and results of operations.
Many of our noninvasive measurement technologies are considered disruptive. These technologies have performance levels that we believe are acceptable for many clinical environments but may be insufficient in others. In addition, these technologies may perform better in some patients and settings than others. Over time, we hope to continue to improve the performance of these technologies and educate the clinical community on how to properly evaluate them. If we are successful in these endeavors, we expect these technologies will become more useful in more environments and will become more widely adopted. Our product portfolio continues to expand, and we are investing significant resources to enter into, and in some cases create, new markets for these products. We are continuing to invest in sales and marketing resources to achieve market acceptance of these products, but are unable to guarantee that our technologies will achieve general market acceptance.
The degree of market acceptance of these products will depend on a number of factors, including but not limited to:
perceived clinical benefits from our products;
perceived cost effectiveness of our products;
perceived safety and effectiveness of our products;
reimbursement available through government and private healthcare programs for using some of our products; and
introduction and acceptance of competing products or technologies.
If our products do not gain market acceptance or if our customers prefer our competitors’ products, our potential revenue growth would be limited, which would adversely affect our business, financial condition and results of operations.
Our ability to commercialize new products, new or improved technologies and additional applications for Masimo SET® and our licensed rainbow® technology is limited to certain markets by our Cross-Licensing Agreement with Cercacor Laboratories, Inc. (Cercacor), which may impair our growth and adversely affect our business, financial condition and results of operations.
Since 1998, we have been a party to a cross-licensing agreement with Cercacor, (as amended, the Cross-Licensing Agreement), under which we granted Cercacor:
an exclusive, perpetual and worldwide license, with sublicense rights, to use all Masimo SET® technology owned by us, including all improvements to this technology, for the monitoring of non-vital signs parameters and to develop and sell devices incorporating Masimo SET® for monitoring non-vital signs parameters in any product market in which a product is intended to be used by a patient or pharmacist rather than by a professional medical caregiver, which we refer to as the “Cercacor Market”; and
a non-exclusive, perpetual and worldwide license, with sublicense rights, to use all Masimo SET® technology owned by us for measurement of vital signs in the “Cercacor Market”.
Non-vital signs measurements consist of body fluid constituents other than vital signs measurements, including, but not limited to, carbon monoxide, methemoglobin, blood glucose, hemoglobin and bilirubin. Under the Cross-Licensing Agreement, we are only permitted to sell devices utilizing Masimo SET® for the monitoring of non-vital signs parameters in markets where the product is intended to be used by a professional medical caregiver, including, but not limited to, hospital caregivers and alternate care facility caregivers, rather than by a patient or pharmacist, which we refer to as the “Masimo Market”.
38

Table of Contents

Accordingly, our ability to commercialize new products, new or improved technologies and additional applications for Masimo SET® is limited. In particular, our inability to expand beyond the “Masimo Market” may limit our ability to maintain or increase our revenue and impair our growth.
Pursuant to the Cross-Licensing Agreement, we have licensed from Cercacor the right to make and distribute products in the “Masimo Market” that utilize rainbow® technology for certain noninvasive measurements. As a result, the opportunity to expand the market for our products incorporating rainbow® technology is also limited, which could limit our ability to maintain or increase our revenue and impair our growth.
We face competition from other companies, many of which have substantially greater resources than we do. If we do not successfully develop and commercialize enhanced or new products that remain competitive with products or alternative technologies developed by others, we could lose revenue opportunities and customers, and our ability to grow our business would be impaired, adversely affecting our financial condition and results of operations.
The medical device industry is intensely competitive and is significantly affected by new product introductions and other market activities of industry participants. A number of our competitors have substantially greater capital resources, larger product portfolios, larger customer bases, larger sales forces and greater geographic presence, have established stronger reputations with specific customers, and have built relationships with Group Purchasing Organizations and other hospital purchasing groups (collectively, GPOs) that may be more effective than ours. Our Masimo SET® platform faces additional competition from companies developing products for use with third-party monitoring systems, as well as from companies that currently market their own pulse oximetry monitors. In addition, competitors with larger product portfolios than ours are engaging in bundling practices, whereby they offer increased discounts to hospitals that purchase their requirements for a variety of different products from the competitor, including products that we do not offer, effectively pricing their competing products at a loss.
Continuing technological advances and new product introductions within the medical device industry place our products at risk of obsolescence. Our long-term success depends upon the development and successful commercialization of new products, new or improved technologies and additional applications for our existing technologies. The research and development process is time-consuming and costly and may not result in products or applications that we can successfully commercialize. In particular, we may not be able to successfully commercialize our products for applications other than arterial blood oxygen saturation and pulse rate monitoring, such as for respiration rate, hemoglobin, carboxyhemoglobin and methemoglobin monitoring. In addition, we may not be able to develop and successfully commercialize new products and technologies that we acquire.
If we do not successfully adapt our products and applications both within and outside these measurements, we could lose revenue opportunities and customers. Furthermore, one or more of our competitors may develop products that are substantially equivalent to those of our products that are cleared or approved for use, or those of our original equipment manufacturer (OEM) partners, in which case a competitor of ours may use our products or those of our OEM partners as predicate devices to more quickly obtain regulatory clearance or approval of their competing products. Competition could result in pressure from our customers to reduce the price of our products and could cause them to place fewer orders for our products, which could, in turn, cause a reduction in our revenues and product gross margins, thereby adversely impacting our business, financial condition and results of operations.
Some of the world’s largest technology companies that have not historically operated in the healthcare or medical device space, such as Alphabet Inc., Amazon.com, Inc., Apple Inc., Samsung Electronics Co., Ltd. and others, have developed or may develop products and technologies that may compete with our current or future products and technologies. For example, in September 2020, Apple, Inc. announced that its Apple Watch Series 6 includes a pulse oximetry monitoring feature, which may compete with certain of our existing products and products in development, including the consumer versions of our iSpO2® and MightySat® pulse oximeters. In addition, in September 2021, Apple, Inc. announced that its Apple Watch Series 7 includes a blood oxygen level monitoring feature and a sleep tracking function, both of which compete with our existing products. These companies have substantially greater capital, research and development, and sales resources than we have. To effectively compete, we may need to expand our product offerings and distribution channels, which in the interim could increase our research and development costs and decrease our operating margins, thereby adversely impacting our business, financial condition and results of operations.
39

Table of Contents

We depend on our domestic and international OEM partners for a portion of our revenue. If they do not devote sufficient resources to the promotion of products that use our technologies, our business would be harmed.
We are, and will continue to be, dependent upon our domestic and international OEM partners for a portion of our revenue through their marketing, selling and distribution of certain of their products that incorporate our technologies. Although we expect that our OEM partners will accept and actively market, sell and distribute products that incorporate our technologies, they may not do so. Because products that incorporate our technologies may represent a relatively small percentage of business for some of our OEM partners, they may have less incentive to promote these products over other products that do not incorporate these technologies.
In addition, some of our OEM partners offer products that compete with ours and also may be involved in intellectual property disputes with us. Therefore, we cannot guarantee that our OEM partners, or any company that may acquire any of our OEM partners, will vigorously promote products incorporating our technologies. The failure of our OEM partners to successfully market, sell or distribute products incorporating our technologies, the termination of OEM agreements, the loss of OEM partners or the inability to enter into future OEM partnership agreements would have a material adverse effect on our business, financial condition and results of operations.
If we fail to maintain or develop relationships with GPOs, sales of our products would decline.
Our ability to sell our products to hospitals depends, in part, on our relationships with GPOs. Many existing and potential customers for our products are members of GPOs. GPOs negotiate pricing arrangements and contracts with medical supply manufacturers and distributors that may include provisions for sole sourcing and bundling, which generally reduce the choices available to member hospitals.
These negotiated prices are made available to a GPO’s members. If we are not one of the providers selected by a GPO, the GPO’s members may be less likely or unlikely to purchase our products. If a GPO has negotiated a strict sole source, market share compliance or bundling contract for another manufacturer’s products, we may be prohibited from making sales to members of such GPO for the duration of such contractual arrangement. Shipments of our pulse oximetry products to customers that are members of GPOs represent approximately 90% of our U.S. product sales. Our failure to renew our contracts with GPOs may cause us to lose market share and could have a material adverse effect on our business, financial condition and results of operations. In addition, if we are unable to develop new relationships with GPOs, our competitive position would likely suffer and our opportunities to grow our revenues and business would be harmed.
Inadequate levels of coverage or reimbursement from governmental or other third-party payers for our products, or for procedures using our products, may cause our revenue to decline or prevent us from realizing revenues from future products.
Sales of our products depend in part on the reimbursement and coverage policies of governmental and private healthcare payers. The lack of adequate coverage and reimbursement for our products or the procedures in which our products are used may deter customers from purchasing our products.
We cannot guarantee that governmental or third-party payers will reimburse or begin reimbursing a customer for the cost of our products or the procedures in which our products are used. For example, some insurance carriers have issued policies denying coverage for transcutaneous hemoglobin measurement on the grounds that the technology is investigational in the outpatient setting. Other payers are continuing to investigate our products to determine if they will provide reimbursement for the use of such products.
These trends could lead to pressure to reduce prices for our current and future products, hinder our ability to obtain market adoption, cause a decrease in the size of the market or potentially increase competition, any of which could have a material adverse effect on our business, financial condition and results of operations.
We do not control payer decision-making with respect to coverage and payment levels for our products. Additionally, we expect many payers to continue to explore cost-containment strategies (e.g., comparative and cost-effectiveness analyses, so-called “pay-for-performance” programs implemented by various public government healthcare programs and private third-party payers, and expansion of payment bundling initiatives, and other such methods that shift medical cost risk to providers) that may potentially impact coverage and/or payment levels for our current products or products we develop in the future.
Outside of the U.S., reimbursement systems vary by country. These systems are often subject to the same pressures to curb rising healthcare costs and control healthcare expenditures as those in the U.S. In addition, as economies of emerging markets develop, these countries may implement changes in their healthcare delivery and payment systems. If adequate levels of reimbursement from third-party payers outside of the U.S. are not obtained, sales of our products outside of the U.S. may be adversely affected.
40

Table of Contents

Consolidation in the healthcare industry could lead to demands for price concessions or to the exclusion of existing market participants from certain markets, which could have an adverse effect on our business, results of operations or financial condition.
Because healthcare costs have risen significantly over the past decade, numerous initiatives and reforms initiated by legislators, regulators and third-party payers to curb these costs have resulted in a consolidation trend in the healthcare industry to aggregate purchasing power. As the healthcare industry consolidates, competition to provide products and services to industry participants has become, and will continue to become, more intense. This has resulted in, and will likely continue to result in, greater pricing pressures and the exclusion of certain existing market participants from important market segments as GPOs, independent delivery networks and large single accounts continue to use their market power to consolidate purchasing decisions for hospitals.
We expect that market demand, government regulation, third-party coverage and reimbursement policies and societal pressures will continue to impact the worldwide healthcare industry, resulting in further business consolidations and alliances among our customers, which may reduce competition, exert further downward pressure on the prices of our products and adversely impact our business, financial condition and results of operations.
Our customers may reduce, delay or cancel purchases due to a variety of factors, such as lower hospital census levels or third-party guidelines, which could adversely affect our business, financial condition and results of operations.
Our customers are facing growing levels of uncertainties, including variations in overall hospital census for paying patients and the impact of such census variations on hospital budgets. As a result, many hospitals are reevaluating their entire cost structure, including the amount of capital they allocate to medical device technologies and products. In addition, certain of our products, including our rainbow® measurements such as carbon monoxide, methemoglobin and hemoglobin, that are sold with upfront license fees and more complex and expensive sensors, could also be impacted by hospital budget reductions. Any reductions in capital spending budgets by hospitals could have a significant negative impact on our OEM customers who, due to their traditionally larger capital equipment sales model, could see declines in purchases from their hospital customers. This, in turn, could reduce our board sales to our OEM customers.
From time to time, states and other local regulatory authorities may issue guidelines regarding the appropriate scope and use of our products. For example, some of our noninvasive monitoring devices may be subject to authorization by individual states as part of the Emergency Medical Services (EMS) scope of practice procedures. A lack of inclusion into scope of practice procedures may limit adoption of our products.
Additionally, increases in demand resulting from global medical crises such as the COVID-19 pandemic may be short lived. If the increased demand results in a stockpiling of our products by, or excess inventory at, our customers, future orders may be delayed or canceled until such on-hand inventory is consumed.
The loss of any large customer or distributor, or any cancellation or delay of a significant purchase by a large customer, could reduce our net sales and harm our operating results.
We have a concentration of OEM, distributor and direct customers. For example, sales to two just-in-time distributors each represented 10% or more of our product sales for the year ended January 1, 2022. We cannot provide any assurances that we will retain our current customers, groups of customers or distributors, or that we will be able to attract and retain additional customers in the future. If for any reason we were to lose our ability to sell to a specific group or class of customers or through a distributor, we could experience a significant reduction in revenue, which would adversely impact our operating results.
Our sales could also be negatively affected by any rebates, discounts or fees that are required by, or offered to, GPOs and customers, including wholesalers or distributors. Additionally, some of our just-in-time distributors have been demanding higher fees, which we may be obligated to pay in order to continue to offer products to our customers through these distributors or which may obligate us to distribute our products directly to our customers. The loss of any large customer or distributor, an increase in distributor fees, or the risks associated with selling directly to our customers could have a material adverse effect on our business, financial condition and results of operations.
41

Table of Contents

Counterfeit Masimo sensors and third-party reprocessed single-patient-use Masimo sensors may harm our reputation. Also, these counterfeit and third-party reprocessed sensors, as well as genuine Masimo reprocessed sensors, are sold at lower prices than new Masimo sensors and could cause our revenue to decline, which may adversely affect our business, financial condition and results of operations.
We believe that other entities are manufacturing and selling counterfeit Masimo sensors. In addition, certain medical device reprocessors have been collecting our used single-patient-use sensors from hospitals and then reprocessing, repackaging and reselling those sensors to hospitals. These counterfeit and third-party reprocessed sensors are sold at lower prices than new Masimo sensors. Our experience with both these counterfeit sensors and third-party reprocessed sensors is that they provide inferior performance, increased sensor consumption, reduced comfort and a number of monitoring problems. Notwithstanding these limitations, some of our customers have indicated a willingness to purchase some of their sensor requirements from these counterfeit manufacturers and third-party reprocessors in an effort to reduce their sensor costs.
These counterfeit and reprocessed sensors have led and may continue to lead to confusion with our genuine Masimo products, have reduced and may continue to reduce our revenue, and, in some cases, have harmed and may continue to harm our reputation if customers conclude incorrectly that these counterfeit or reprocessed sensors are original Masimo sensors.
In addition, we have expended a significant amount of time and expense investigating issues caused by counterfeit and reprocessed sensors, troubleshooting problems stemming from such sensors, educating customers about why counterfeit and reprocessed sensors do not perform to their expectations, enforcing our proprietary rights against the counterfeit manufacturers and reprocessors, and enforcing our contractual rights.
In response to these counterfeit sensors and third-party reprocessors, we have incorporated X-Cal® technology into certain products to ensure our customers get the performance they expect by using genuine Masimo sensors and that such sensors do not continue to be used beyond their useful life. However, some customers may object to the X-Cal® technology, potentially resulting in the loss of customers and revenues.
We also offer our own Masimo reprocessed sensors, which meet the same performance specifications as our new Masimo sensors, to our customers. Reprocessed sensors sold by us are also offered at a lower price and, therefore, may reduce certain customer demand for our new sensors. As a result, increased sales of our own Masimo reprocessed sensors may result in lower revenues, which could negatively impact our business, financial condition and results of operations.
42

Table of Contents


Risks Related to Our Intellectual Property
If the patents we own or license, or our other intellectual property rights, do not adequately protect our technologies, we may lose market share to our competitors and be unable to operate our business profitably.
Our success depends significantly on our ability to protect our rights to the technologies used in our products. Our utilization of patent protection, trade secrets and a combination of copyright and trademark laws, as well as nondisclosure, confidentiality and other contractual arrangements, to protect our intellectual property afford us only limited protection and may not adequately protect our rights or permit us to gain or maintain any competitive advantage.
Certain of our patents related to our technologies have begun to expire. Upon the expiration of our issued or licensed patents, we generally lose some of our rights to exclude competitors from making, using, selling or importing products using the technology based on the expired patents.
Furthermore, in recent years, the U.S. Supreme Court has ruled on several patent cases and several laws have been enacted that, in certain situations, potentially narrow the scope of patent protection available and weaken the rights of patent owners. As a result, we believe large technology companies may be pursuing an “efficient infringement” strategy, having concluded that it is cheaper to infringe third party intellectual property rights than to acquire, license or otherwise respect them. There can be no assurance that we will be successful in securing additional patents on commercially desirable improvements, that such additional patents will adequately protect our innovations or offset the effect of expiring patents, or that competitors will not be able to design around our patents.
In addition, third parties have challenged, and may continue to challenge, our issued patents through procedures such as Inter-Partes Review (IPR). In many IPR challenges, the U.S. Patent and Trademark Office (PTO) cancels or significantly narrows issued patent claims. IPR challenges could increase the uncertainties and costs associated with the maintenance, enforcement and defense of our issued and future patents and could have a material adverse effect on our business, financial condition and results of operations.
We also utilize unpatented proprietary technology and know-how and often rely on confidentiality agreements and intellectual property assignment agreements with our employees, OEM partners, independent distributors and consultants to protect such unpatented proprietary technology and know-how. However, such agreements may not be enforceable or may not provide meaningful protection for our proprietary information in the event of unauthorized use or disclosure or other breaches of the agreements, or in the event that our competitors discover or independently develop similar or identical designs or other proprietary information.
We rely on the use of registered and common law trademarks with respect to the brand names of some of our products. Common law trademarks provide less protection than registered trademarks. Loss of rights in our trademarks could adversely affect our business, financial condition and results of operations.
If third parties claim that we infringe their intellectual property rights, we may incur liabilities and costs and may have to redesign or discontinue selling certain products.
Searching for existing intellectual property rights may not reveal important intellectual property and our competitors may also have filed for patent protection, which may not be publicly-available information, or claimed trademark rights that have not been revealed through our searches. In addition, some of our employees were previously employed at other medical device companies. We may be subject to claims that our employees have disclosed, or that we have used, trade secrets or other proprietary information of our employees’ former employers. Our efforts to identify and avoid infringing on third parties’ intellectual property rights may not always be successful. Any claims of patent or other intellectual property infringement against us, even those without merit, could:
be expensive and time-consuming to defend and result in payment of significant damages to third parties;
force us to stop making or selling products that incorporate the intellectual property;
require us to redesign, reengineer or rebrand our products, product candidates and technologies;
require us to enter into royalty agreements that would increase the costs of our products;
require us to indemnify third parties pursuant to contracts in which we have agreed to provide indemnification for intellectual property infringement claims;
divert the attention of our management and other key employees; and
43

Table of Contents

result in our customers or potential customers deferring or limiting their purchase or use of the affected products impacted by the claims until the claims are resolved;
any of which could have a material adverse effect on our business, financial condition and results of operations. In addition, new patents obtained by our competitors could threaten the continued commercialization of our products in the market even after they have already been introduced.
We believe competitors may currently be violating and may in the future violate our intellectual property rights. As a result, we may initiate litigation to protect and enforce our intellectual property rights, which may result in substantial expense and may divert management’s attention from implementing our business strategy.
We believe that the success of our business depends, in part, on obtaining patent protection for our products and technologies, defending our patents and preserving our trade secrets. We were previously involved in significant litigation to protect our patent positions related to some of our pulse oximetry signal processing patents that resulted in various settlements. We believe some of the new market entrants in the healthcare and monitoring space, including some of the world’s largest technology companies, may be infringing our intellectual property, and we may be required to engage in additional litigation to protect our intellectual property in the future. In addition, we believe that certain individuals who previously held high level technical and clinical positions with us misappropriated our intellectual property for the benefit of themselves and other companies. For example, on January 9, 2020, we initiated litigation against Apple Inc. for infringement of a number of patents, for trade secret misappropriation and for ownership and correction of inventorship of a number of Apple Inc. patents that list one of our former employees as an inventor. Our ongoing and future litigation could result in significant additional costs and further divert the attention of our management and key personnel from our business operations and the implementation of our business strategy and may not be successful or adequate to protect our intellectual property rights.
The laws of foreign countries may not adequately protect our intellectual property rights.
Intellectual property protection laws in foreign countries differ substantially from those in the U.S. If we fail to apply for intellectual property protection in foreign countries, or if we cannot adequately protect our intellectual property rights in these foreign countries, our competitors may be able to compete more effectively against us, which could adversely affect our competitive position, as well as our business, financial condition and results of operations.
Risks Related to Our Regulatory Environment
Our failure to obtain and maintain FDA clearances or approvals on a timely basis, or at all, would prevent us from commercializing our current, upgraded or new products in the U.S., which could severely harm our business.
Unless an exemption applies, each medical device that we market in the U.S. must first undergo premarket review pursuant to the Federal Food, Drug, and Cosmetic Act (FDCA) by receiving clearance of a 510(k) premarket notification, receiving clearance through the de novo classification review process or obtaining approval of a premarket approval (PMA) application. Even if regulatory clearance or approval of a product is granted, the U.S. Food and Drug Administration (FDA) may clear or approve our products only for limited indications for use. Additionally, the FDA may not grant 510(k) clearance on a timely basis, if at all, for new products or new uses that we propose for Masimo SET® or licensed rainbow® technology.
The traditional FDA 510(k) clearance process for our products has generally taken between four to nine months. However, our more recent experience and interactions with the FDA, along with information we have received from other medical device manufacturers, suggests that, in some cases, the FDA is requiring applicants to provide additional or different information and data for 510(k) clearance than it had previously required, and that the FDA may not rely on approaches that it had previously accepted to support 510(k) clearance. As a result, FDA 510(k) clearance can be delayed for our products in some cases.
To support our product applications to the FDA, we frequently are required to conduct clinical testing of our products. Such clinical testing must be conducted in compliance with FDA requirements pertaining to human research. Among other requirements, we must obtain informed consent from study subjects and approval by institutional review boards before such studies may begin. We must also comply with other FDA requirements such as monitoring, record-keeping, reporting and the submission of information regarding certain clinical trials to a public database maintained by the National Institutes of Health. In addition, if the study involves a significant risk device, we are required to obtain the FDA’s approval of the study under an Investigational Device Exemption (IDE). Compliance with these requirements can require significant time and resources. In addition, public health emergencies and other extraordinary circumstances may disrupt the conduct of our clinical trials. If the FDA determines that we have not complied with such requirements, the FDA may refuse to consider the data to support our applications or may initiate enforcement actions.
Even though 510(k) clearances have been obtained, if safety or effectiveness problems are identified with our products, we may need to initiate a recall of such products. Furthermore, our new products or significantly modified marketed products could be
44

Table of Contents

denied 510(k) clearance and be required to undergo the more burdensome PMA or de novo classification review processes. The process of obtaining a de novo classification or PMA approval is much more costly, lengthy and uncertain than the process for obtaining 510(k) clearance.
De novo classification review generally takes six months to one year from the time of submission of the de novo request, although it can take longer. Approval of a PMA generally takes one year from the time of submission of the PMA, but may be longer.
We sell consumer versions of our iSpO2® and MightySat® pulse oximeters that are not intended for medical use. Some of our products or product features may not be subject to the 510(k) process and/or other regulatory requirements in accordance with specific FDA guidance and policies, such as the FDA guidance related to mobile medical applications. In addition, some of our products or product features may not be subject to device regulation pursuant to Section 520(o) of the FDCA, which excludes certain software functions from the statutory definition of a device. In addition, we may market certain products pursuant to enforcement discretion policies the FDA previously announced to address the need for these products as a result of the COVID-19 pandemic. Such policies only remain in effect during the public health emergency, such that we will need to seek clearance or approval of such products to continue marketing these products at the end of the COVID-19 pandemic. If the FDA changes its policies or concludes that our marketing of these products is not in accordance with its current policies and/or Section 520(o) of the FDCA, we may be required to seek clearance or approval of these devices through the 510(k), de novo classification review or PMA processes.
The failure of our OEM partners to obtain required FDA clearances or approvals for products that incorporate our technologies could have a negative impact on our revenue.
Our OEM partners are required to obtain their own FDA clearances in the U.S. for most products incorporating Masimo technologies. The FDA clearances we have obtained may not make it easier for our OEM partners to obtain clearances of products incorporating these technologies, or the FDA may not grant clearances on a timely basis, if at all, for any futur
